Mitsubishi MELSERVO-J4 Servomotor With Break 5kW HG-SR502BJ

Mitsubishi MELSERVO-J4 Servomotor With Break 5kW HG-SR502BJ
MELSERVO-J4 SERIES 50W to 7KW(HG-KR and HG-MR series)
We are First Class mitsubishi servomotors dealer and mitsubishi servomotors distributor in China.
We can Supply mitsubishi electric automation parts,such as Mitsubishi PLC,Mitsubishi Servo Motor&mitsubishi servo drive,Mitsubishi HMI,Mitsubishi VFD and So on.
100% Original and new,In stock by Mitsubishi Automation
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Mitsubishi MELSERVO-J4 Servomotor	motor	HG-SR 1000 r/min series (Compatible with 3-phase 200 V AC, medium inertia/medium capacity)						HG-SR 2000 r/min series (Compatible with 3-phase 200 V AC, medium inertia/medium capacity)
Mitsubishi MR-J4 Servomotor	motor	51(B)	81(B)	121 (B)	201 (B)	301 (B)	421 (B)	52(B)	102 (B)	152 (B)	202 (B)	352 (B)	502 (B)	702 (B)
Continuous running duty (Note 1) Rated output	[kW]	0.5	0.85	1.2	2.0	3.0	4.2	0.5	1.0	1.5	2.0	3.5	5.0	7.0
Rated torque	[N•m]	4.8	8.1	11.5	19.1	28.6	40.1	2.4	4.8	7.2	9.5	16.7	23.9	33.4
Maximum torque (Note 10, 13)	[N•m]	14.3	24.4	34.4	57.3	85.9	120	7.2	14.3	21.5	28.6	50.1	71.6	100 (134)
Rated speed (Note 1)	[r/min]	1000						2000
Maximum speed (Note 10)	[r/min]	1500						3000
Instantaneous permissible speed (Note 10)	[r/min]	1725						3450
Power rate at continuous rated torque Standard	[kW/s]	19.7	41.2	28.1	46.4	82.3	107	7.85	19.7	32.1	19.5	35.5	57.2	74.0
Rated current	[A]	2.8	5.2	7.1	9.4	13	19	2.9	5.6	9.4	9.6	14	22	26
Maximum current (Note 13)	[A]	9.0	17	23	30	42	61	9.0	17	29	31	45	70	83 (116)
Environment (Note 5) Ambient temperature	Operation	0 °C to 40 °C (non-freezing)
	Storage	-15 °C to 70 °C (non-freezing)
Ambient humidity	Operation	10 %RH to 80 %RH (non-condensing)
	Storage	10 %RH to 90 %RH (non-condensing)
Permissible load for the shaft (Note 8) L	[mm]	55		79				55			79
Radial	[N]	980		2058				980			2058
Thrust	[N]	490		980				490			980
Mass (Note 3) Standard	[kg]	6.2	7.3	11	16	20	27	4.8	6.2	7.3	11	16	20	27
