Transformer capacity kVA | Rated primary current A | Crest value of first wave
(multiple) |
Model |
Rating A | Crest value of first wave
(multiple) |
Model |
Rating A | Crest value of first wave
(multiple) |
Model |
Rating A |
5 |
23.8 |
45 |
NF125-CV(*1)
NF125-CV, NF125-SV, NF125-HV NF125-SEV, NF125-HEV |
60
100 50 |
37 |
NF63-CV(*1) NF125-CV(*1)
NF125-CV, NF125-SV |
50
60 75 |
24 |
NF63-CV(*1)
NF63-CV, NF63-SV NF125-CV(*2) NF125-SV |
30
50 (50) 50 |
7.5 |
35.7 |
45 |
NF250-CV, NF250-SV, NF250-HV NF250-SEV, NF250-HEV | 150
125 |
37 |
NF125-SEV NF125-CV(*1)
NF250-CV, NF250-SV |
50
75 125 |
24 |
NF63-CV(*1) NF125-CV(*1)(*2)
NF125-CV, NF125-SV |
50
60(50) 75 |
10 |
47.6 |
43 |
NF250-CV, NF250-SV, NF250-HV NF250-SEV, NF250-HEV | 200
125 |
37 |
NF125-CV(*1)
NF250-CV, NF250-SV NF250-SEV |
100
150 125 |
24 |
NF125-CV(*1)
NF125-CV, NF125-SV |
60
100 |
15 |
71.4 |
43 |
NF400-CW NF400-SW
NF400-SEW, NF400-HEW |
400
300 200 |
35 |
NF250-CV, NF250-SV NF250-SEV | 225
125 |
23 |
NF125-CV(*1)
NF250-CV, NF250-SV |
100
150 |
20 | 95.2 | 43 | NF400-SW
NF400-SEW, NF400-HEW |
400
200 |
35 | NF400-SW
NF400-SEW |
350
200 |
23 | NF250-CV, NF250-SV
NF250-SEV |
200
125 |
30 | 143 | 37 | NF400-SEW, NF400-HEW
NF630-SW |
200
500 |
34 | NF400-SEW | 200 | 23 | NF400-SW
NF400-SEW |
300
200 |
50 | 238 | 35 | NF630-SEW(*1)
NF1000-SEW |
300
500 |
34 | NF630-SEW | 300 | 23 | NF400-SEW(*1)
NF630-SEW |
300
300 |
75 | 357 | 30 | NF800-SEW(*1)
NF1250-SEW |
400
600 |
29 | NF800-SEW(*1) | 400 | 22 | NF630-SEW | 400 |
100 | 476 | 27 | NF1000-SEW | 800 | 28 | NF1600-SEW | 800 | 20 | NF800-SEW(*1) | 600 |
150 | 714 | 24 | − | − | 24 | − | − | 19 | NF1600-SEW | 800 |
200 | 952 | 21 | − | − | 22 | − | − | 19 | − | − |
300 | 1429 | 17 | − | − | 18 | − | − | 16 | − | − |
500 | 2381 | − | − | − | 17 | − | − | − | − | − |
