Mitsubishi Process CPU PLC Module Q Series Q12PHCPU

Series#: Mitsubishi PLC CPU Module Q Series

Product Details

  • Mitsubishi Process CPU PLC Module Q Series Q12PHCPU
  • Mitsubishi PLC Controller Module PLC Mitsubishi MELSEC-Q Series
  • We are First Class mitsubishi plc dealer and mitsubishi plc distributor in China.
  • We can Supply mitsubishi electric automation parts,such as Mitsubishi PLC,Mitsubishi Servo Motor,Mitsubishi HMI,Mitsubishi VFD and So on,
  • 100% Original and new,In stock by Mitsubishi PLC
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

Item Q02PHCPU Q06PHCPU Q12PHCPU Q25PHCPU
Control method Stored program cyclic operation
I/O control mode Refresh
Sequence control language • Relay symbol language (ladder)• Logic symbolic language (list)• MELSAP3 (SFC), MELSAP-L

• Function block

• Structured text (ST)

Process controllanguage • Process control FBD*1
Peripheralconnection port USB
Peripheralconnection port RS-232
Memory card interface (SRAM card, Flash card, ATA card)
LD instruction 34 ns
MOV instruction 102 ns
PC MIX value(instruction/µs)*3 10.3
Floating point addition 0.78 µs
Total number of instructions*4 757
Floating point instruction
Character string processing instruction
PID instruction
Process control instruction
Special function instruction (Trigonometric function, square root,exponential operation, etc.)  
Constant scan(Function for keeping regular scan time) 0.5…2000 ms (setting available in units of 0.5 ms)
Program capacity 28K steps 60K steps 124K steps 252K steps
Number of I/O device points [X/Y] 8192 points
Number of I/O points [X/Y] 4096 points
Internal relay [M]*5 8192 points
Latch relay [L]*5 8192 points
Link relay [B]*5 8192 points
Timer [T]*5 2048 points
Retentive timer [ST]*5 0 point
Counter [C]*5 1024 points
Data register [D]*5 12288 points
Link register [W]*5 8192 points
Annunciator [F]*5 2048 points
Edge relay [V]*5 2048 points
Link special relay [SB] 2048 points
Link special register [SW] 2048 points
File register [R, ZR] 65536 points*6 131072 points*6
Step relay [S] 8192 points
Index register [Z] 16 points
Pointer [P] 4096 points
Interrupt pointer [I] 256 points
Special relay [SM] 2048 points
Special register [SD] 2048 points
Function input [FX] 16 points
Function output [FY] 16 points
Function register [FD] 5 points
Local device
Device initial values
