Mitsubishi Q series CPU Pulse input/high-speed counter modules QD62 QD62E QD65PD2 QD62D

(DC input sinking output type)

(DC input sourcing output type)

(differential input sinking output type)

(DC input)

(DC input, sink output type)

(DC/Differential input, external output terminals)

Count input signal

Phase

Signal level

5/12/24 V DC 2…5 mA

Differential line driver level (AM26LS31 [manufactured by Texas Instruments] or equivalent)

5 V DC

6.4…11.5 mA

(manufactured by Texas Instruments Incorporated)

or equivalent)

EIA Standards RS-422-A, differential line driver level

(AM26LS31 [manufactured by Texas Instruments] or equivalent)

[DC input] 5/12/24 V DC, 7…10 mA

Pulse input

Function

· Ring counter function ·Count disable function

· Coincidence output function ·Sampling counter function

· Preset function ·Periodic pulse counter function

·Ring counter function

·Coincidence detection function

·Preset function

·Periodic pulse counter function

·Ring counter function

·Coincidence detection function

·Continuous comparison function

·Preset function

·Latch counter function

·Ring counter function replace function

·Coincidence output function ·Internal clock function

·Cam switch function ·Frequency measurement function

·Preset/replace function ·Rotation speed measurement

·Latch counter function function

·Count disable function ·Pulse measurement function

·Sampling counter function ·PWM output function

· Periodic pulse counter function ·General input function

·Count disable/preset/ ·General output function replace function
