Mitsubishi VFDs Inverter Three-phase | Mitsubishi VFDs Inverter FR-D720 0.1KW to 15kW | ||||||||||
Model FR-D720-oK | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 15 |
Model FR-D720-o-NA | 008 | 014 | 025 | 042 | 070 | 100 | 165 | 238 | 318 | — | — |
Applicable motor capacity (kW)*1 | 0.1 | 0.2 | 0.4 | 0.75 | 1.5 | 2.2 | 3.7 | 5.5 | 7.5 | 11 | 15 |
Rated capacity (kVA)*2 | 0.3 | 0.6 | 1.0 | 1.7 | 2.8 | 4.0 | 6.6 | 9.5 | 12.7 | 17.9 | 23.1 |
Rated current (A) | 0.8 | 1.4 | 2.5 | 4.2 | 7.0 | 10.0 | 16.5 | 23.8 | 31.8 | 45.0 | 58.0 |
Overload current rating*3 | 150% 60s, 200% 0.5s (inverse-time characteristics) | ||||||||||
Voltage*4 | Three-phase 200 to 240V | ||||||||||
Regenerative braking torque*5 | 150% | 100% | 50% | 20% | |||||||
Rated input AC voltage/frequency | Three-phase 200 to 240V 50Hz/60Hz | ||||||||||
Permissible AC voltagefluctuation | 170 to 264V 50Hz/60Hz | ||||||||||
Permissible frequency fluctuation | ±5% | ||||||||||
Power supply capacity (kVA)*6 | 0.4 | 0.7 | 1.2 | 2.1 | 4.0 | 5.5 | 9.0 | 12.0 | 17.0 | 20.0 | 27.0 |
Protective structure (JEM1030) | Enclosed type (IP20). | ||||||||||
Cooling system | Self-cooling | Forced air cooling | |||||||||
Approximate mass (kg) | 0.5 | 0.5 | 0.8 | 1.0 | 1.4 | 1.4 | 1.8 | 3.6 | 3.6 | 6.5 | 6.5 |
