Novotechnik NOVOHALL Angle Sensor non-contacting Series RSA-3200 RSC-3200

Series#: Novotechnik Rotary Sensor

Product Details

  • Novotechnik non-contacting NOVOHALL Rotary Sensor Series RSA-3200 RSC-3200
  • We are First Class Novotechnik Transducer sensor dealer and Novotechnik Transducer sensor distributor in China.
  • We can Supply all kinds of  Novotechnik Transducer sensor parts,such as Novotechnik Linear Position Transducers,Novotechnik Rotary Sensor,Novotechnik Signal Conditioners and ect.
  • All parts are 100% Original and new in stock by novotechnik and fast delivery time within 1 day
  • 100% after sale service and technology Support
  • MOQ: 1pcs
Qty:

Specification

Type designations RSC-3202-8 -2 -521
Mechanical Data
Dimensions see drawing
Mounting with 2 M4 screws
Starting torque of mounting screws 200 … 300 Ncm
at housing flange
Mechanical travel 360 continuous °
Maximum operational speed mechanical unlimited
Weight approx. 25 g
Electrical Data
Maximum permissible applied voltage 5 (4.5 … 5.5) VDC
Current consumption without load typ. 15 (typ 8 on request) per channel mA
Reverse polarity protection yes, supply lines
Short-circuit protection yes (vs. GND and Ub)
Measuring range 0….60 up to 0…360 in 5 angles availbable (s. ordering code) °
Number of channels 2
Update rate 2.5 kHz
Resolution 12 bit
Repeatability 0.5 °
Absolute linearity at measuring angle 60° 120° / 180° 240° / 360°

2.0 1.5 1.0



± % FS

(additional ±0.3 % at FS at electrical code 229 for channel 2)
Interlinearity 3 ± % FS
Output signal ratiometric to Ub 0.25…4.75

VDC

0.5…4.5

(load resistance > 1 kΩ)

VDC
Temperature error at measuring angle 60° 120° / 180° 240° / 360°

< 1.1 < 0.7 typ. 0.5



± % FS

(additional ±0.3 % at FS at electrical code 229 for channel 2)
Environmental Data
Temperature range – 40 up to +125 °C
Vibration (IEC 60068-2-6) 5….2000

Amax = 0.75

amax = 20

Hz mm g
Shock (IEC 60068-2-27) 50 (11 ms) g
MTTF (DIN EN ISO 13849, 285 (per channel) Years
parts count method, w/o load)
Functional safety If you need assistance in using our products in safety-related systems,
please contact us
Protection class (ISO 20653) IP6k7 / IP6k9k (mounted with O-ring)
EMC compatibility ISO 11452-2 Radiated EM HF-fields, Absorber Hall 100 V/m ISO 11452-5 Radiated EM HF-fields, Stripline 100 V/m

ISO 10605 (Kap. 5.2) Packaging and Handling + Component Test 8 kV ISO 10605 (Kap. 5.3) Powered up test 8 kV

CISPR 25 Radiated Emission, class 5

Interference emission and immunity according to ECE-R10 (E1)
