Novotechnik NOVOPAD Transducer up to 1000 mm touchless Series TF1

Series#: Novotechnik Linear Position Transducers

Product Details

  • Novotechnik NOVOPAD Transducer up to 1000 mm touchless Series TF1
  • We are First Class Novotechnik Transducer sensor dealer and Novotechnik Transducer sensor distributor in China.
  • We can Supply all kinds of  Novotechnik Transducer sensor parts,such as Novotechnik Linear Position Transducers,Novotechnik Rotary Sensor,Novotechnik Signal Conditioners and ect.
  • All parts are 100% Original and new in stock by novotechnik and fast delivery time within 1 day
  • 100% after sale service and technology Support
  • MOQ: 1pcs
Qty:

Specification



Type designations TF1- _ _ _ _-001 – 41 _ – 102

Voltage

TF1- _ _ _ _-001 – 42 _ – 102

Current

Electrical Data
Electrical measuring range (dimension B) 0100 up to 1000 mm
Output signal 0,1 … 10 V (load > 5 kΩ) 4 … 20 mA (burden < 500 Ω)
Number of channels 1
Update rate (internal) > 10 kHz
Signal propagation delay < 1 ms
Resolution

Dimension B < 400 mm Dimension B > 400 mm



10

20



µm

µm

Absolute linearity < 0.025 (min. ± 100 µm) ±% FS
Tolerance of electr. zero point 1 ± mm
Reproducibility Dimension B < 400 mm Dimension B > 400 mm

10

20



µm

µm

Hysteresis < 10 µm
Temperature error < 15 (min. 0.01 mm/K) ppm/K
Supply voltage 24 (18 … 32) VDC
Supply voltage ripple < 10 % Vss
Power drain (w/o load) 2.4 W
Overvoltage protection 36 (permanent) VDC
Polarity protection Yes, up to supply voltage max VDC
Short circuit protection Yes (outputs vs. GND and supply voltage max.)
Insulation resistance (500 VDC) > 10
Environmental Data
MTTF (DIN EN ISO 13849-1

parts count method, w/o load, wc)

> 20 Years
Novotechnik Analog TF1-0800-001-411-102 TF1-0800-001-421-102
Novotechnik Analog TF1-0800-001-413-102 TF1-0800-001-422-102
Novotechnik Analog TF1-0800-001-414-102 TF1-0800-001-423-102
Novotechnik Analog TF1-0800-001-424-102
