Item Model | G9EB-1(-B) |
Contact resistance *1 | 30 mΩ max. |
Contact voltage drop | 0.1 V max. (for a carry current of 25 A) |
Operate time | 30 ms max. |
Release time | 15 ms max. |
Between coil and contacts | 1,000 MΩ min. |
Between contacts of the same polarity | 1,000 MΩ min. |
Between coil and contacts | 2,500 VAC, 1 min |
Between contacts of the same polarity | 2,500 VAC, 1 min |
Impulse withstand voltage *3 | 4,500 V |
Destruction | 10 to 55 to 10 Hz, 0.75-mm single amplitude
(Acceleration: 2.94 to 88.9 m/s2) |
Malfunction | 10 to 55 to 10 Hz, 0.75-mm single amplitude
(Acceleration: 2.94 to 88.9 m/s2) |
Destruction | 490 m/s2 |
Malfunction | 100 m/s2 |
Mechanical endurance *4 | 100,000 operations min. |
Electrical endurance (resistive load) *5 *6 | 250 VDC, 25 A, 30,000 ops. min. |
Short-time carry current | 50 A (5 min), 40 A (10 min) |
Maximum interruption current *6 | 100 A at 250 VDC (5 times) |
Overload interruption *6 | 50 A at 250 VDC (50 times min.) |
Ambient operating temperature | -40 to 70°C (with no icing or condensation) |
Ambient operating humidity | 5% to 85% RH |
Weight (including accessories) | Approx. 135 g |
