Type | Standard | Model for Sensor Communications Unit *1 |
||
NPN output | E3X-HD11 | E3X-HD6 | E3X-HD14 | E3X-HD0 |
PNP output | E3X-HD41 | E3X-HD8 | E3X-HD44 | |
Connecting method | Pre-wired | Wire-saving Connector *2 |
M8 connector |
Communications Unit connector |
Light source (wavelength) | Red, 4-element LED (625 nm) | |||
Power supply voltage | 12 to 24 VDC ±10%, ripple (P-P) 10% max. | Supplied from the connector through the Sensor Communications Unit |
||
Normal mode | 720 mW max. (Current consumption: 30 mA max. at 24 VDC, 60 mA max. at 12 VDC) |
|||
Eco ON | 530 mW max. (Current consumption: 22 mA max. at 24 VDC, 44 mA max. at 12 VDC) |
|||
Eco LO | 640 mW max. (Current consumption: 26 mA max. at 24 VDC, 53 mA max.at 12 VDC) |
– | ||
Control output | Load power supply voltage: 26.4 VDC max., open- collector output Load current: Groups of 1 to 3 Amplifier Units: 100mA max., Groups of 4 to 16 Amplifier Units: 20mA max. Residual voltage: At load current of less than 10 mA: 1 V max., At load current of 10 to 100 mA: 2 V max. OFF current: 0.1 mA max. |
– | ||
Protection circuits | Power supply reverse polarity protection, output short-circuit protection and output reverse polarity protection |
Power supply reverse polarity protection and output short- circuit protection |
||
Super-high-speed mode (SHS) *3 |
NPN outputs: Operate or reset: 50 μs PNP outputs: Operate or reset: 55 μs |
– | ||
High-speed Mode (HS) |
Operate or reset: 250 μs (default setting) | |||
Standard Mode (STND) |
Operate or reset: 1 ms | |||
Giga-power Mode (GIGA) |
Operate or reset: 16 ms | |||
Maximum connectable Units | 16 units | with E3X-CRT: 16 units with E3X-ECT: 30 units |
||
Mutual interference prevention |
Possible for up to 10 units (optical communications sync) *3 | |||
Auto power control (APC) | Always ON | |||
Other functions | Power tuning, differential detection, DPC, timer (OFF-delay, ON-delay, or one-shot), zero reset, resetting settings, and Eco mode |
|||
Ambient illumination (Receiver side) |
Incandescent lamp: 20,000 lx max., Sunlight: 30,000 lx max. | |||
Ambient temperature range | OOperating: Groups of 1 to 2 Amplifiers: -25 to 55°C, Groups of 3 to 10 Amplifiers: -25 to 50°C, Groups of 11 to 16 Amplifiers: -25 to 45°C Storage: -30 to 70°C (with no icing or condensation) |
Operating: Groups of 1 to 2 Amplifiers: 0 to 55°C, Groups of 3 to 10 Amplifiers: 0 to 50°C, Groups of 11 to 16 Amplifiers: 0 to 45°C, Groups of 17 to 30 Amplifiers: 0 to 40°C Storage: -30 to 70°C (with no icing or condensation) |
||
Ambient humidity range | Operating and storage: 35% to 85% (with no condensation) | |||
Insulation resistance | 20 MΩ min. (at 500 VDC) | |||
Dielectric strength | 1,000 VAC at 50/60 Hz for 1 minute | |||
Vibration resistance (destruction) |
10 to 55 Hz with a 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
10 to 150 Hz with a 0.7-mm double amplitude for 80 minutes each in X, Y, and Z directions |
||
Shock resistance (destruction) |
500 m/s2 for 3 times each in X, Y, and Z directions |
150 m/s2 for 3 times each in X, Y, and Z directions |
||
Degree of protection | IEC 60529 IP50 (with Protective Cover attached) |
– | ||
Weight (packed state/unit only) |
Approx. 105 g/ Approx. 65 g |
Approx. 60 g/ Approx. 20 g |
Approx. 70 g/ Approx. 25 g |
Approx. 65 g/Approx. 25 g |
Case | Polycarbonate (PC) | Heat-resistant ABS (connector: PBT) |
||
Cover | Polycarbonate (PC) | |||
Cable | PVC | – | ||
Accessories | Instruction Manual |
