| Contact structure | 2-pole (DPDT) | 2-pole (DPDT) | 3-pole (3PDT) | 4-pole (4PDT) | 4-pole (4PDT) | 4-pole (4PDT) |
| Contact structure | Single | Bifurcated | Single | Single | Bifurcated | Crossbar bifurcated (CBG) |
| Contact resistance*1 *2 | 50 mΩ max. | 100 mΩ max. | ||||
| Operate time*3 | 20 ms max. | |||||
| Release time*3 | 20 ms max. | |||||
| Mechanical | 18,000 operations/h | |||||
| Rated load | 1,800 operations/h | |||||
| Insulation resistance*4 | 100 MΩ min. | |||||
| Between coil and contacts | 2,000 VAC, 50/60 Hz for 1 min | |||||
| Between contacts of the same polarity | 1,000 VAC at 50/60 Hz for 1 min | 700 VAC at 50/60 Hz
for 1 min |
||||
| Destruction | 10 to 55 to 10 Hz, 0.5-mm single amplitude (1.0-mm double amplitude) | |||||
| Malfunction | 10 to 55 to 10 Hz, 0.5-mm single amplitude (1.0-mm double amplitude) | |||||
| Destruction | 1,000 m/s2 | |||||
| Malfunction | 200 m/s2 | |||||
|
Mechanical |
AC: 50,000,000operations min. DC: 100,000,000
operations min. (switching frequency: 18,000 operations/h) |
AC: 50,000,000operations min. DC: 50,000,000
operations min. (switching frequency: 18,000 operations/h) |
AC: 50,000,000operations min. DC: 100,000,000
operations min. (switching frequency: 18,000 operations/h) |
AC: 50,000,000operations min. DC: 100,000,000
operations min. (switching frequency: 18,000 operations/h) |
AC: 20,000,000operations min. DC: 20,000,000
operations min. (switching frequency: 18,000 operations/h) |
AC: 50,000,000operations min. DC: 50,000,000
operations min. (switching frequency: 18,000 operations/h) |
| Electrical*5 | 500,000 operations min. (rated load, switching frequency: 1,800 operations/h) | 200,000 operations min. (rated load, switching frequency: 1,800 operations/h) | 500,000 operations min. (rated load, switching frequency: 1,800 operations/h) | 200,000 operations min. (rated load, switching frequency: 1,800 operations/h) | 100,000 operations min. (rated load, switching frequency: 1,800 operations/h) | 50,000 operations min. (rated load, switching frequency: 1,800 operations/h) |
| Failure rate P value (reference value)*6 | 1 mA at 5 VDC | 100 ?A at 1 VDC | 1 mA at 5 VDC | 1 mA at 1 VDC | 100 ?A at 1 VDC | 100 ?A at 1 VDC |
| Weight | Approx. 35 g | Approx. 35 g | Approx. 35 g | Approx. 35 g | Approx. 35 g | Approx. 35 g |
