| 2 poles | 4 poles | |
| Contact resistance *1 | 100 mΩ max. | |
| Operation time *2 | 20 ms max. | |
| Release time *2 | 20 ms max. | |
| Mechanical | 18, 000 operations/h | |
| Rated load | 2,400 operations/h | |
| Insulation resistance *3 | 1,000 MΩ min. | |
| Between coil and contacts | 2,000 VAC at 50/60 Hz for 1 min. | |
| Between contacts of different polarity | 2,000 VAC at 50/60 Hz for 1 min. | |
| Between contacts of the same polarity | 1,000 VAC at 50/60 Hz for 1 min. | |
| Destruction | 10 to 55 to 10 Hz, Double amplitude: 1.0 mm | |
| Malfunction | 10 to 55 to 10 Hz, Double amplitude: 1.0 mm | |
| Destruction | 1,000 m/s2 (approx. 100 G) | |
| Malfunction | 200 m/s2 (Approx. 20 G) | |
| Mechanical | 50,000,000 operations (switching frequency: 18,000 operations/h) | |
| Electrical *4 | 500,000 operations (switching frequency: 2,400 operations/h) | 200,000 operations (switching frequency: 2,400 operations/h) |
| Ambient operating temperature | Standard models: -55 to 70°C (with no icing or condensation)
Models with LED operation indicators: -40 to 70°C (with no icing or condensation) |
|
| Ambient humidity | 5% to 85% | |
| Weight | Approx. 35 g | |
