| Contact resistance |
100 mW max. |
| Operate time |
10 ms max. |
| Release time |
5 ms max. |
| Bounce time |
Operate: Approx. 0.6 ms Release: Approx. 7.2 ms |
| Max. switching frequency |
Mechanical: 18,000 operations/hrElectrical: 1,800 operations/hr (under rated load) |
| Insulation resistance |
100 MW min. (at 500 VDC) |
| Dielectric strength |
750 VAC, 50/60 Hz for 1 min between contacts of same polarity 2,000 VAC, 50/60 Hz for 1 min between coil and contacts |
| Impulse withstand voltage |
4,500 V between coil and contacts |
| Vibration resistance |
Destruction: 10 to 55 Hz, 1.5-mm double amplitude Malfunction: 10 to 55 Hz, 1.5-mm double amplitude |
| Shock resistance |
Destruction: 1,000 m/s2 (approx. 100G) Malfunction: 100 m/s2 (approx. 10G) |
| Life expectancy |
Mechanical:10,000,000 operations min. (at 18,000 operations/hr) Electrical: 100,000 operations min. (at 1,800 operations/hr) |
| Ambient temperature |
Operating: –40°C to 85°C |
| Ambient humidity |
Operating: 35% to 85% |
| Weight |
Approx. 12 g |
