Sensing method | Through-beam | |||
NPN output | E3JK-TN11 | E3JK-TN12 | E3JK-TN13 | E3JK-TN14 |
PNP output | E3JK-TP11 | E3JK-TP12 | E3JK-TP13 | E3JK-TP14 |
Sensing distance | 40 m | 5 m | 40 m | 5 m |
Standard sensing object | Opaque: 17-mm dia. min. | |||
Differential travel | – | |||
Directional angle | Both Emitter and Receiver 3° min. | |||
Light source (wavelength) | Red LED (624 nm) | Infrared LED (850 nm) | ||
Power supply voltage | 10 to 30 VDC, including ripple (p-p): 10% | |||
DC | 40 mA max. (Emitter 25 mA max. Receiver 15 mA max.) | |||
AC | – | |||
Control output | Load power supply voltage: 30 V max., Load current: 100 mA max., Residual voltage: 3 V max., open- collector output (NPN/PNP output depending on model), Light-ON/Dark-ON selectable | |||
Protection circuits | Power supply reverse polarity protection, Output short-circuit protection, and Output reverse polarity protection | |||
Response time | 1 ms max. | |||
Sensitivity adjustment | One-turn adjuster Receiver (E3JK-T@@@-D) only | |||
Ambient illumination (Receiver side) | Incandescent lamp: 3,000 lx max., Sunlight: 11,000 lx max. | |||
Ambient temperature range | Operating: -25°C to 55°C, Storage: -40°C to 70°C (with no icing or condensation) | |||
Ambient humidity range | Operating: 35% to 85%, Storage: 35% to 95% (with no condensation) | |||
Insulation resistance | 20 MΩ min. at 500 VDC | |||
Dielectric strength | 1,500 VAC, 50/60 Hz for 1 min | |||
Destruction | 10 to 55 Hz with a 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions | |||
Malfunction | 10 to 55 Hz with a 1.5 mm double amplitude for 2 hours each in X, Y, and Z directions | |||
Destruction | 500 m/s2 for 3 times each in X, Y, and Z directions | |||
Malfunction | 500 m/s2 for 3 times each in X, Y, and Z directions | |||
Degree of protection | IEC 60529 IP64 | |||
Connection method | Pre-wired (standard length: 2 m) | |||
Weight (packed state) | Approx. 300 g | |||
Case | ABS (Acrylonitrile Butadiene Styrene) | |||
Lens/Display window | Methacrylic resin | |||
Adjuster | POM | |||
Cable | PVC | |||
Bending radius of cable | R18 | |||
Accessories | Instruction manual |
