Omron Photoelectric Sensors E3Z-R61 E3Z-R66 E3Z-L61 E3Z-L66 E3Z-R81 E3Z-R86

Omron Photoelectric Sensors E3Z-R61 E3Z-R66 E3Z-L61 E3Z-L66 E3Z-R81 E3Z-R86

Series#: Omron Photoelectric Sensors

Product Details

Omron Photoelectric Sensors E3Z-R61 E3Z-R66 E3Z-R81 E3Z-R86
The Standard for Photoelectric Sensors with a Secure Track Record of One Million Sold Yearly.
Longsensing distance of 30 m for Through-beam Models, 4 m for Retro-reflective Models, and 1 m for Diffuse-reflective
Mechanicalaxis and optical axis offset of less than ±5° simplifies optical axis adjustment.
High stability with unique algorithm that prevents interference of external light.

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Sensing method	Through-beam			Retro-reflective with MSR function	Diffuse-reflective (Narrow- beam Models)
NPN out- put Pre-wired	E3Z-T61	E3Z-T62	E3Z-T61A	E3Z-R61	E3Z-D61	E3Z-D62	E3Z-L61
Connector (M8)	E3Z-T66	E3Z-T67	E3Z-T66A	E3Z-R66	E3Z-D66	E3Z-D67	E3Z-L66
Pre-wired	E3Z-T81	E3Z-T82	E3Z-T81A	E3Z-R81	E3Z-D81	E3Z-D82	E3Z-L81
Connector (M8)	E3Z-T86	E3Z-T87	E3Z-T86A	E3Z-R86	E3Z-D86	E3Z-D87	E3Z-L86
Sensing distance	15 m	30 m	10 m	4 m (100 mm) 1 (when using E39-R1S) 3 m (100 mm) 1 (when using E39-R1)	100 mm (white paper: 100 ´ 100 mm)	1 m (white paper: 300 ´ 300 mm)	90 + 30 mm (white paper, 100 x 100 mm)
Spot diameter (reference value)	—						(2.5 dia. and sensing dis- tance of 90 mm)
Standard sensing object	Opaque: 12-mm dia. min.			Opaque: 75-mm dia. min.	—
Minimum detectable object (reference value)	—						0.1 mm (cop- per wire)
Differential travel	—				20% max. of setting distance		Refer to Engi- neering data on page 8.
Directional angle	Both emitter and receiver: 3 to 15°			2 to 10°	—
Light source (wavelength)	Infrared LED (870 nm)		Red LED (660 nm)	Red LED (660 nm)	Infrared LED (860 nm)		Red LED (650 nm)
Current consumption	35 mA max. (Emitter: 15 mA max., Receiv- er: 20 mA max.)			30 mA max.
Protection circuits	Reversed power supply polarity protection, Output short-circuit protection, and Re- versed output polarity protection			Reversed power supply polarity protection, Output short-circuit protection, Mutual interference prevention, and Reversed output polarity protection
Response time	Operate or reset: 1 ms max.	Operate or reset: 2 ms max.	Operate or reset: 1 ms max.
Degree of protection	IEC, IP67
Connection method	Pre-wired cable (standard length: 2 m and 0.5 m), Connector (M8)
Weight (packedstate) Pre-wired cable (2 m)	Approx. 120 g			Approx. 65 g
Connector	Approx. 30 g			Approx. 20 g
Material Case	PBT (polybutylene terephthalate)
Lens	Modified polyarylate			Methacrylic resin	Modified polyarylate
