Omron Photomicro sensor EE-SA701 EE-SA801

Product Details

  •  Conforms to standards for semiconductor FOUP cassettes to enable accurately detecting FOUP cassettes without being affected by the material, color, or reflectance of the bottoms of the cassettes.
  • Thin design enables mounting in a wider range of applications, e.g., on transfer arms.
  • Increased visibility with 4-direction indicator.
  • Optical detection of actuator operation provides a long life (mechanical life: 5 million operations min.).
  • Models available with PNP or NPN output.
  • Models are available with very flexible robot cable
Qty:

Specification

Models EE- SPY801/802
Sensing distance
(Standard sensing object)
0 to 5 mm ( White paper: 15 × 15 mm2, reflection factor: 90%)
0 to 3 mm ( Black paper: 15 × 15 mm2, reflection factor: 10%)
Sensing object Transparent or opaque wafer carriers
Operation indicator Lit orange when object is detected.
Light source GaAs infrared LED with a peak wavelength of 940 nm
Supply voltage 12 to 24 VDC ±10%, ripple (p-p): 5% max.
Current consumption 30 mA max.
Control output NPN open collector:
Load power supply voltage: 5 to 24 VDC
Load current: 100 mA max.
OFF current: 0.5 mA max.
100 mA load current with a residual voltage of 0.8 V max.
40 mA load current with a residual voltage of 0.4 V max.
Response time 5 ms max.
Ambient illumination 3,000 lx max. with incandescent light or sunlight on the surface of the receiver
Ambient temperature range Operating: – 10 to +55 ° C
Storage: – 25 to +65 ° C (with no icing)
Ambient humidity range Operating: 5% to 85%
Storage: 5% to 95% (with no condensation)
Vibration resistance Destruction: 1 to 500 Hz, 1.0-mm single amplitude or 150 m/s2 each in X, Y, and Z directions
3 times and for 11 min. each
Shock resistance Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions
Degree of protection IEC IP30
Connecting method Pre-wired (Standard length: 2 m)
Weight (packaged) Sensor: Approx. 43 g; Accessory (Pedestal): Approx. 9 g
Model NPN output EE-SA801A EE-SA801A-R EE-SA701-R
PNP output EE-SA801R EE-SA801R-R EE-SA701P-R
Indicator Light red when actuator is pressed. Lit red while there is no load
on actuator
Free position (FP) 5.0±0.4 mm
Operating position (OP) 3.5 to 4.5 mm *2
Total travel position (TTP) 0 mm max.
Operating load *3 3 N max. (typical: 0.5 N)
Supply voltage 12 to 24 VDC±10%, ripple (p-p): 10% max.
Current consumption 35 mA max.
Control output NPN Models:
NPN open collector, 5 to 24 VDC, 50 mA max.;
residual voltage of 0.4 V max. at 50-mA load current
OFF current: 0.5 mA max.
PNP Models:
PNP open collector, 5 to 24 VDC, 50 mA max.;
residual voltage of 0.4 V max. at 50-mA load current
OFF current: 0.5 mA max.
Protection circuits Reversed power supply polarity protection
Ambient temperature range Operating: -25 to +55°C
Storage: -30 to +60°C (with no icing or condensation)
Ambient humidity range Operating: 5% to 85%
Storage: 5% to 95% (with no condensation)
Mechanical durability 5,000,000 operations min. (One operation is from the free position to operating
position and back to the free position.)
Vibration resistance Destruction: 10 to 500 Hz, 1.0-mm single amplitude or 150 m/s2 3 times each in
X, Y, and Z directions for 11 min. each
Shock resistance Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions
Degree of protection IEC IP40
Connecting method Pre-wired (standard cable
length: 1 m)
Pre-wired (robot cable length: 1 m)
Weight Approx. 16.1 g
