| Item | CS1W-DA041 | CS1W-DA08V | CS1W-DA08C | ||
| Applicable PLC model | CS series | ||||
| Unit type | CS1 Special I/O Unit | ||||
| Isolation *1 | Between I/O and PLC signals: Photocoupler (No isolation between individual I/O signals.) | ||||
| External terminals | 21-point detachable terminal block (M3 screws) | ||||
| Power consumption | 130 mA max. at 5 VDC,
180 mA max. at 26 VDC |
130 mA max. at 5 VDC,
180 mA max. at 26 VDC |
130 mA max. at 5 VDC,
250 mA max. at 26 VDC |
||
| Dimensions (mm) *2 | 35 ´ 130 ´ 126 (W ´ H ´ D) | ||||
| Weight | 450 g max. | ||||
| General specifications | Conforms to general specifications for SYSMAC CS-series Series. | ||||
| Mounting position | CS-series CPU Rack or CS-series Expansion Rack
(Cannot be mounted to a C200H Expansion I/O Rack or a SYSMAC BUS Slave Rack.) |
||||
| Maximum number of Units | Depends on the Power Supply Unit. *3 | ||||
|
Data exchange with CPU Units *4 |
Special I/O Unit Area
CIO 200000 to CIO 295915 (Words CIO 2000 to CIO 2959) |
||||
| Internal Special I/O Unit DM Area (D20000 to D29599) | |||||
| Number of analog outputs | 4 | 8 | 8 | ||
|
Output signal ranges *5 |
1 to 5 V/4 to 20 mA
0 to 5 V 0 to 10 V -10 to 10V |
1 to 5 V
0 to 5 V 0 to 10 V -10 to 10 V |
4 to 20 mA |
||
| Output impedance | 0.5 Ω max. (for voltage output) | ||||
| Max. output current (for 1 point) | 12 mA (for voltage output) | ||||
| Maximum permissible load resistance | 600 Ω (current output) *9 | – | 600 Ω (current output) *8 | ||
| Resolution | 4,000 (full scale) | ||||
| Set data | 16-bit binary data | ||||
|
Accuracy *6 |
23±2°C: | Voltage output: ±0.3% of full scale Current output: ±0.5% of full scale | |||
| 0°C to 55°C: Voltage output: ±0.5% of full scale Current output: ±0.8% of full scale | |||||
| D/A conversion time *7 | 1.0 ms/point max. | ||||
|
Output functions |
Output hold function |
Outputs the specified output status (CLR, HOLD, or MAX) under any of the following circumstances. When the Conversion Enable Bit is OFF. *8
In adjustment mode, when a value other than the output number is output during adjustment. When there is an output setting error or a fatal error occurs at the PLC. When the CPU Unit is on standby. When the Load is OFF. |
|||
