Omron PLC CS-series Process Analog I/O Units CS1W-PTS02 CS1W-PTS03/PTS12/PTS52

Series#: Omron PLC

Product Details

  • Up to eight analog inputs can be connected for each Unit.
  • Thereis isolation between input channels, so unwanted circuit paths between thermocouple inputs can be  (Except for CS1W-PTR01/ 02)
  • Output scaling(±32,000)
  • Process value alarms (HH, H, L,LL)
  • Input disconnectionalarm
  • Rate-of-change calculation andalarm
  • Top/bottom/valley hold (CS1W-PTS11/PTS12/PDC11only)
  • Up to four analog set values can be output for each
  • All outputs are
  • Output rate-of-changelimit
  • Output high/lowlimits
  • Output scaling(±32,000)
  • Control output answer input (CS1W-PMV01only)
  • Provides up to four pulses from a device such as a displacement flowmeter. The accumulated value can also be calculated at the sametime and transferred to the CPU Unit at each cycle. (CS1W-PPS01)
Qty:

Specification

Item Specifications
Model CS1W-PTS03
Applicable PLC CS Series
Unit type CS-series Special I/O Unit
Mounting position CS-series CPU Rack or CS-series Expansion Rack (Cannot be mounted to C200H Expansion I/O Rack or SYSMAC BUS Remote I/O Slave Rack.)
Maximum number of Units 80 (within the allowable current consumption and power consumption range)
Unit numbers 00 to 95 (Cannot duplicate Special I/O Unit numbers.)


Special I/O Unit Area

10 words/Unit

Resistance Thermometer Input Unit to CPU Unit:

All process values, process value alarms (LL, L, H, HH), rate-of-change values, rate-of-change alarms (L, H), disconnection alarms



DM Area words allocated to Special I/O Units

100 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Temperature sensor type, input range (user set), scaling of process value data to be stored in allocated words in CIO area, number of items for moving average, process value alarm setting (LL, L, H, HH), rate-of-change alarm setting (L, H), zero/span adjustment value, etc.

Number of temperature sensor inputs 4


Temperature sensor types



Ni508.4

Input range and scaling to industrial units are separate for each of the 4 inputs.

Note: Sensor type, input range, and scaling to industrial units are set in the DM Area.



Input ranges

The input range can be set within a range of –50 to 150°C (variable setting).

Note: Internally, inputs are processed in the above range (refer to Table 2 below), so accuracy and resolution accord with this internal range.

Example:

Input range: -50 to 100°C; industrial unit scaling: -50.0 to 100.0°C. DM Area settings are as follows:

Input signal maximum: 1000 (03E8 hex) Input signal minimum: -500 (FE0C hex)

Industrial unit maximum value stored: 1000 (03E8 hex) Industrial unit minimum value stored: -500 (FE0C hex)



Scaling in industrial units

Data to be stored in the allocated words in the CIO area must be scaled (with the minimum and maximum values set). Data can be stored at 0% to 100%.


Data storage in the CIO Area

The value derived from carrying out the following processing in order of the actual process data in the input range is stored in four digits hexadecimal (binary values) in the allocated words in the CIO Area.

1) Mean value processing ® 2) Scaling ® 3) Zero/span adjustment ® 4) Output limits



Item Specifications
Model CS1W-PTS12
Applicable PLC CS Series
Unit type CS-series Special I/O Unit
Mounting position CS-series CPU Rack or CS-series Expansion Rack (Cannot be mounted to C200H Expansion I/O Rack or SYSMAC BUS Remote I/O Slave Rack.)
Maximum number of Units 80 (within the allowable current consumption and power consumption range)
Unit numbers 00 to 95 (Cannot duplicate Special I/O Unit numbers.)
Special I/O Unit Area 10 words/Unit

Resistance Thermometer Input Unit to CPU Unit:

All process values, process value alarms (LL, L, H, HH), rate-of-change values, rate-of-change alarms (L, H), disconnection alarms, adjustment period end/notices.



DM Area words allocated to Special I/O Units

100 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Temperature sensor type, input range (user set), scaling of process value data to be stored in allocated words in CIO area, rate-of-change input range, scaling of rate-of-change data, number of items for moving average, process value alarm setting (LL, L, H, HH), rate-of-change alarm setting (L, H), zero/span adjustment value.



Expansion Control/ Monitor Area words

35 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Hold function selection start/reset, adjustment period control, control bits Resistance Thermometer Input Unit to CPU Unit:

Adjustment period warnings/notices, peak and bottom values, top and valley values

Expansion Setting Area words 46 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Expansion Setting Area settings, adjustment period control, peak and bottom detection, top and valley detection

Number of temperature sensor inputs 4
Temperature sensor type Pt100 (JIS, IEC), JPt100, Pt50, Ni508.4

Sensor type, input range, and scaling to industrial units are separate for each of the 4 inputs.

Scaling Data to be stored in the allocated words in the CIO area must be scaled (with the minimum and maximum values set by user) (4 inputs set separately.). Data can be stored at 0% to 100%.


Data storage in the CIO Area

The value derived from carrying out the following processing in order of the actual process data in the input range is stored in four digits hexadecimal (binary values) in the allocated words in the CIO Area.

1) Mean value processing ® 2) Scaling ® 3) Zero/span adjustment ® 4) Output limits

Accuracy (25°C) The greater of the following: ±0.05% or ±0.1°C
Item Specifications
Model CS1W-PTS12
Applicable PLC CS Series
Unit type CS-series Special I/O Unit
Mounting position CS-series CPU Rack or CS-series Expansion Rack (Cannot be mounted to C200H Expansion I/O Rack or SYSMAC BUS Remote I/O Slave Rack.)
Maximum number of Units 80 (within the allowable current consumption and power consumption range)
Unit numbers 00 to 95 (Cannot duplicate Special I/O Unit numbers.)


Special I/O Unit Area

10 words/Unit

Resistance Thermometer Input Unit to CPU Unit:

All process values, process value alarms (LL, L, H, HH), rate-of-change values, rate-of-change alarms (L, H), disconnection alarms, adjustment period end/notices.



DM Area words allocated to Special I/O Units

100 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Temperature sensor type, input range (user set), scaling of process value data to be stored in allocated words in CIO area, rate-of-change input range, scaling of rate-of-change data, number of items for moving average, process value alarm setting (LL, L, H, HH), rate-of-change alarm setting (L, H), zero/span adjustment value.



Expansion Control/ Monitor Area words

35 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Hold function selection start/reset, adjustment period control, control bits Resistance Thermometer Input Unit to CPU Unit:

Adjustment period warnings/notices, peak and bottom values, top and valley values

Expansion Setting Area words 46 words/Unit

CPU Unit to Resistance Thermometer Input Unit:

Expansion Setting Area settings, adjustment period control, peak and bottom detection, top and valley detection

Number of temperature sensor inputs 4
Temperature sensor type Pt100 (JIS, IEC), JPt100, Pt50, Ni508.4

Sensor type, input range, and scaling to industrial units are separate for each of the 4 inputs.

Scaling Data to be stored in the allocated words in the CIO area must be scaled (with the minimum and maximum values set by user) (4 inputs set separately.). Data can be stored at 0% to 100%.


Data storage in the CIO Area

The value derived from carrying out the following processing in order of the actual process data in the input range is stored in four digits hexadecimal (binary values) in the allocated words in the CIO Area.

1) Mean value processing ® 2) Scaling ® 3) Zero/span adjustment ® 4) Output limits

Accuracy (25°C) The greater of the following: ±0.05% or ±0.1°C
