| Item |
CP1W-TS001 |
CP1W-TS002 |
CP1W-TS101 |
CP1W-TS102 |
|
Thermocouples |
Platinum resistance thermometer |
| Temperature sensors |
Switchable between K and J, but same type must be used for all inputs. |
Switchable between Pt100 and JPt100, but same type must be used for all inputs. |
| Number of inputs |
2 |
4 |
2 |
4 |
| Allocated input words |
2 |
4 |
2 |
4 |
| Accuracy |
(The larger of ±0.5% of converted value or ±2°C) ±1 digit max. * |
(The larger of ±0.5% of converted value or ±1°C) ±1 digit max. |
| Conversion time |
250 ms for 2 or 4 input points |
| Converted temperature data |
16-bit binary data (4-digit hexadecimal) |
| Isolation |
Photocouplers between all temperature input signals |
| Current consumption |
5 VDC: 40 mA max., 24 VDC: 59 mA max. |
5 VDC: 54 mA max., 24 VDC: 73 mA max. |
