| Item Classification | Bifurcated contacts | Encased models |
| Contact resistance*1 | 25 mΩ max. | 50 mΩ max. |
| Operation time*2 | AC: 20 ms max., DC: 30 ms max. | |
| Release time*2 | 20 ms max., (*4 40 ms max.) | |
| Mechanical | 18,000 operations/h | |
| Rated load | 1,800 operations/h | |
| Insulation resistance*3 | 100 MΩ min. | |
| 2 poles Between coil and contacts | 2,000 VAC at 50/60 Hz for 1 min. | |
| 1,000 VAC at 50/60 Hz for 1 min. | ||
|
3 pole Between coil and contacts |
1,500 VAC at 50/60 Hz for 1 min. | |
| 1,000 VAC at 50/60 Hz for 1 min. | ||
| Destruction | 10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude) | |
| Malfunction | 10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) | |
| Destruction | 1,000 m/s2 | |
| Malfunction | 100 m/s2 | |
| Mechanical | 5,000,000 operations min. (operating frequency: 18,000 operations/hr) | |
| Electrical*5 | 500,000 operations min. (rated load, switching frequency: 1,800 operations/h) | |
| Failure rate P level (reference value*6) | 100 mA at 1 VDC | 10 mA at 1 VDC |
| Weight | Approx. 85 g | |
