| Item Classification |
Bifurcated contacts |
Encased models |
| Contact resistance*1 |
25 mΩ max. |
50 mΩ max. |
| Operation time*2 |
AC: 20 ms max., DC: 30 ms max. |
| Release time*2 |
20 ms max., (*4 40 ms max.) |
| Mechanical |
18,000 operations/h |
| Rated load |
1,800 operations/h |
| Insulation resistance*3 |
100 MΩ min. |
| 2 poles Between coil and contacts |
2,000 VAC at 50/60 Hz for 1 min. |
| |
1,000 VAC at 50/60 Hz for 1 min. |
| 3 pole Between coil and contacts |
1,500 VAC at 50/60 Hz for 1 min. |
| |
1,000 VAC at 50/60 Hz for 1 min. |
| Destruction |
10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude) |
| Malfunction |
10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) |
| Destruction |
1,000 m/s2 |
| Malfunction |
100 m/s2 |
| Mechanical |
5,000,000 operations min. (operating frequency: 18,000 operations/hr) |
| Electrical*5 |
500,000 operations min. (rated load, switching frequency: 1,800 operations/h) |
| Failure rate P level (reference value*6) |
100 mA at 1 VDC |
10 mA at 1 VDC |
| Weight |
Approx. 85 g |
