Size | M8 | M12 | M18 | M30 | ||||
Shielded | Shielded | Unshielded | Shielded | Unshielded | Shielded | Unshielded | Shielded | Unshielded |
Item Model | E2E-X2D@ | E2E-X4MD@ | E2E-X3D@ | E2E-X8MD@ | E2E-X7D@ | E2E-X14MD@ | E2E-X10D@ | E2E-X20MD@ |
Sensing distance | 2 mm ±10% | 4 mm ±10% | 3 mm ±10% | 8 mm ±10% | 7 mm ±10% | 14 mm ±10% | 10 mm ±10% | 20 mm ±10% |
Set distance *1 | 0 to 1.6 mm | 0 to 3.2 mm | 0 to 2.4 mm | 0 to 6.4 mm | 0 to 5.6 mm | 0 to 11.2 mm | 0 to 8 mm | 0 to 16 mm |
Differential travel | 15% max. of sensing distance | 10% max. of sensing distance | ||||||
Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on pages 17 and 18. | |||||||
Standard sensing object | Iron,
8 ´ 8 ´ 1 mm |
Iron,
20 ´ 20 ´ 1 mm |
Iron,
12 ´ 12 ´ 1 mm |
Iron,
30 ´ 30 ´ 1 mm |
Iron,
18 ´ 18 ´ 1 mm |
Iron, 30 ´ 30 ´ 1 mm | Iron,
54 ´ 54 ´ 1 mm |
|
Response frequency
*2 |
1.5 kHz | 1 kHz | 0.8 kHz | 0.5 kHz | 0.4 kHz | 0.1 kHz | ||
Power supply voltage (operating voltage range) | Standard Models: 12 to 24 VDC, ripple (p-p): 10% max. (10 to 30 VDC) US Models and Connector Models Used as UL-certified Models:
12 to 24 VDC, ripple (p-p): 10% max. (The operating voltage range is also the same.) *3 |
|||||||
Leakage current | 0.8 mA max. | |||||||
Load current | 3 to 100 mA, Diagnostic output: 50 mA for -D1(5)S Models | |||||||
Residual voltage | 3 V max. (Load current: 100 mA, Cable length: 2 m, M1J-T Models only: 5 V max.) | |||||||
Indicators | D1 Models: Operation indicator (red) and setting indicator (green) D2 Models: Operation indicator (red) | |||||||
Operation mode (with sensing object approaching) |
D1 Models: NO Refer to the timing charts under I/O Circuit Diagrams on page 20 for details. D2 Models: NC |
|||||||
Diagnostic output delay | 0.3 to 1 s | |||||||
Protection circuits | Surge suppressor, Load short-circuit protection (for control and diagnostic output) | |||||||
Ambient temperature range | Operating: -25 to 70°C, Storage: -40 to 85°C (with no icing or condensation) | |||||||
Ambient humidity range | Operating/storage: 35% to 95% (with no condensation) | |||||||
Temperature influence | ±15% max. of sensing distance at 23°C in the temperature range of -25 to 70°C | ±10% max. of sensing distance at 23°C in the temperature range of -25 to 70°C | ||||||
Voltage influence | ±1% max. of sensing distance at rated voltage in the rated voltage ±15% range | |||||||
Insulation resistance | 50 MΩ min. (at 500 VDC) between current-carrying parts and case | |||||||
Dielectric strength | 1000 VAC, 50/60 Hz for 1 minute between current carry parts and case | |||||||
Vibration resistance | Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions | |||||||
Shock resistance |
Destruction: 500 m/s2
10 times each in X, Y, and Z directions |
Destruction: 1,000 m/s2 10 times each in X, Y, and Z directions |
||||||
Degree of protection | Pre-wired Models: IEC 60529 IP67, in-house standards: oil-resistant Connector Models: IEC 60529 IP67 | |||||||
Connection method | Pre-wired Models (Standard cable length: 2 m), Connector Models, or Pre-wired Connector Models (Standard cable length: 0.3 m) |
