Model
Item |
E2S-W13 E2S-W14 | E2S-Q13 E2S-Q14 | E2S-W23 E2S-W24 | E2S-Q23 E2S-Q24 | E2S-W15 E2S-W16 | E2S-Q15 E2S-Q16 | E2S-W25 E2S-W26 | E2S-Q25 E2S-Q26 |
Sensing surface | Top | Front | Top | Front | Top | Front | Top | Front |
Sensing distance | 1.6 mm ±15% | 2.5 mm ±15% | 1.6 mm ±15% | 2.5 mm ±15% | ||||
Set distance | 0 to 1.2 mm | 0 to 1.9 mm | 0 to 1.2 mm | 0 to 1.9 mm | ||||
Differential travel | 10% max. of sensing distance | |||||||
Detectable object | Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on page 4.) | |||||||
Standard sensing object | Iron, 12 ´ 12 ´ 1 mm | Iron, 15 ´ 15 ´ 1 mm | Iron, 12 ´ 12 ´ 1 mm | Iron, 15 ´ 15 ´ 1 mm | ||||
Response frequency * | 1 kHz min. | |||||||
Power supply voltage (operating voltage range) |
12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max. |
|||||||
Current consumption | 13 mA max. at 24 VDC (no-load) | |||||||
Load current | NPN open-collector output, 50 mA max. (30 VDC max.) | PNP open-collector output, 50 mA max. (30 VDC max.) | ||||||
Residual voltage | 1.0 V max. (under load current of 50 mA with cable length of 1 m) | |||||||
Indicators | Operation indicator (orange) | |||||||
Operation mode (with sensing object approaching) | @@3 Models: NO
@@4 Models: NC Refer to the timing charts under I/O Circuit Diagrams on page 5 for details. |
@@5 Models: NO
@@6 Models: NC Refer to the timing charts under I/O Circuit Diagrams on page 5 for details. |
