Omron Relay Terminal G70D-VSOC16 / VFOM16

Series#: Omron Terminal Relays

Product Details

Qty:

Specification

Item G70D-VSOC16 G70D-VFOM16
Relay outputs Power MOSFET Relay outputs
Contact configuration 16 points (SPST-NO × 16)
Contact structure Single
Contact resistance 100 mΩ max. *1
Isolation method Photocoupler
Must-operate time 10 ms max. *2 10 ms max.
Release time 10 ms max. *2 15 ms max.
Output ON-resistance 2.4 Ω max.
Open-circuit leakage current 10 mA max. (at 125 V DC)
Max. switching frequency Mechanical: 18,000 operations/h Rated load: 1,800 operations/h
Insulation resistance 100 MΩ min. (at 500 V DC)
Dielectric strength 2,000 V AC for 1 min between coil and contact 2,000 V AC for 1 min between input and output terminals


Noise immunity

Power input (normal mode): 600 V for 10 min with a pulse width of 100 ns to 1 ms Power input (common mode): 1.5 kV for 10 min with a pulse width of 100 ns to 1 ms Input cable (coiling): 1.5 kV for 10 min with a pulse width of 100 ns to 1 ms

Unit body (coiling): 600 V for 10 min with a pulse width of 100 ns to 1 ms

Vibration resistance Destruction: 10 to 55 to 10 Hz, 0.5-mm amplitude (1.0-mm double) Malfunction: 10 to 55 to 10 Hz, 0.375-mm amplitude (0.75-mm double)
Shock resistance Destruction: 300 m/s2, Malfunction: 100 m/s2
Operating voltage range 24 V DC +10%/–15%
Current consumption Approx. 170 mA at 24 V DC *3 Approx. 125 mA at 24 V DC *4
Cable length Between block and controller: 5 m max. (reference value for AWG28) Between block and external device: Dependent on load
LED color Operation indicator: orange
Coil surge absorber Diode (600 V, 1 A)
Ambient temperature Operating: -25 to 55°C (with no icing or condensation)
Ambient humidity Operating: 45% to 85%
Mounting strength No damage when 49 N pull load was applied for 1 s in all directions (except for 9.8 N in direction of rail)
Terminal strength Tightening torque: 0.78 to 118 N·m Pull strength: 49 N for 1 min
Weight *5 Approx. 280 g
