| Contact resistance (see note 2) |
100 mΩ max. |
| Operate time |
10 ms max. (approx. 3 ms) |
| Release time |
15 ms max. (approx. 4 ms) |
| Insulation resistance |
1,000 MΩ min. (at 500 VDC) |
| Dielectric strength |
2,000 VAC, 50/60 Hz for 1 min between coil and contacts2,000 VAC, 50/60 Hz for 1 min between contacts of different polarity 1,000 VAC, 50/60 Hz for 1 min between contacts of same polarity 250 VAC, 50/60 Hz for 1 min between coils of different polarity |
| Vibration resistance |
Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude) Malfunction: 10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude) |
| Shock resistance |
Destruction: 1,000 m/s2 (approx. 100G) Malfunction: 100 m/s2 (approx. 10G) |
| Endurance |
Mechanical: 50,000,000 operations min. (at 18,000 operations/hr) Electrical: 100,000 operations min. (at 1,800 operations/hr, rated load)500,000 operations min. for long-life at 2 A 100,000 operations min for long-life at 5 A |
| Ambient temperature |
Operating: –25°C to 55°C (with no icing or condensation)Storage: –25°C to 55°C (with no icing or condensation) |
| Ambient humidity |
Operating: 35% to 85% |
| Weight |
Approx. 75 g |
