Panasonic Digital Fiber Sensor FX-301/-301B/-301G FX-301H/-301P/-301BP/-301GP

Series#: Panasonic Digital Fiber Sensor

Product Details

Qty:

Specification

Type Standard type
Type Red LED Blue LED Green LED Infrared LED


NPN output

FX-301 FX-301B FX-301G FX-301H
PNP output FX-301P FX-301BP FX-301GP FX-301HP
Supply voltage 12 to 24 V DC ±10 % Ripple P-P 10 % or less
Power consumption <Red LED / Infrared LED type>
Normal operation: 960 mW or less (Current consumption 40 mA or less at 24 V supply voltage)
ECO mode: 600 mW or less (Current consumption 25 mA or less at 24 V supply voltage)<Blue LED / Green LED type>
Normal operation: 720 mW or less (Current consumption 30 mA or less at 24 V supply voltage)
ECO mode: 430 mW or less (Current consumption 18 mA or less at 24 V supply voltage)
Output <NPN output type>
NPN open-collector transistor
• Maximum sink current:100 mA (50 mA, if five, or more, amplifiers are connected in cascade.)
• Applied voltage: 30 V DC or less (between output and 0 V)
• Residual voltage: 1.5 V or less [at 100 mA (at 50 mA, if five, or more, amplifiers are connected in cascade) sink current.]<PNP output type>
PNP open-collector transistor
• Maximum source current: 100 mA (50 mA, if five, or more, amplifiers are connected in cascade.)
• Applied voltage: 30 V DC or less (between output and +V)
• Residual voltage: 1.5 V or less [at 100 mA (at 50 mA, if five, or more, amplifiers are connected in cascade) source current.]
Response time 65 μs or less [H-SP (Red LED type only)], 150 μs or less (FAST),
250 μs or less [STD / S-D (Red LED type only)],
2 ms or less (LONG), selectable with jog switch
Sensitivity setting 2-point teaching / Limit teaching / Manual adjustment / Full-auto teaching / Max. sensitivity teaching
Operation indicator Orange LED (lights up when the output is ON)
Stability indicator Green LED (lights up under stable light received condition or stable dark condition)
MODE indicator RUN: Green LED, TEACH • ADJ • L/D ON • TIMER • PRO: Yellow LED
Digital display 4 digit red LED display
Fine sensitivity
adjustment function
Incorporated
Timer function Incorporated with variable ON-delay / OFF-delay / ONE SHOT timer, switchable either effective or ineffective.
[Timer period: Red LED type; 0.5 ms approx., 1 to 9,999 ms
(Blue LED, Green LED, Infrared LED type; approx. 0.5 to 500 ms)]
Light emitting amount
selection function
Incorporated (Red LED type only) (Note 3)
FAST, STD, LONG: 4 level, H-SP: 3 level, S-D: 2 level
Automatic interference
prevention function
Incorporated (Up to four sets of fiber heads can be mounted close together. However, 2 fiber heads in H-SP mode.) (Note 4)
Ambient temperature -10 to +55 ℃ +14 to +131 ℉
(If 4 to 7 units are connected in cascade: -10 to +50 ℃ +14 to +122 ℉, if 8 to 16 units are connected in cascade: -10 to +45 ℃ +14 to +113 ℉)
(No dew condensation or icing allowed),
Storage: -20 to +70 ℃ -4 to +158 ℉
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance Incandescent light: 3,000 ℓx at the light-receiving face
Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure (Note 6)
Insulation resistance 20 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure (Note 6)
Vibration resistance 10 to 150 Hz frequency, 0.75 mm 0.030 in amplitude in X, Y and Z directions for two hours each
Shock resistance 98 m/s2 acceleration (10 G approx.) in X, Y and Z directions for five times each
Emitting element (modulated) Red LED Blue LED Green LED Infrared LED
Material Enclosure: Heat-resistant ABS, Case cover: Polycarbonate, MODE key: Acrylic, Jog switch: Heat-resistant ABS (FX-301B/G/H: Acrylic)
Connecting method Connector (Note 7)
Cable length Total length up to 100 m 328.084 ft (50 m 164.042 ft for 5 to 8 units, 20 m 65.617 ft for 9 to 16 units) is possible with 0.3 mm2, or more, cable.
Weight Net weight: 20 g approx., Gross weight: 25 g approx.
Accessory FX-MB1 (amplifier protection seal): 1 set
