Panasonic Digital Laser Sensor LS-H92/-H92F/-H91 LS-H21/-H21F/-H21-A/-H22F

Series#: Panasonic Laser Sensor

Product Details

Qty:

Specification

Type Coaxial retroreflective
Type Class 2 Class 1


IEC / JIS / GB standards
conforming type

LS-H92 LS-H91 LS-H91-A
FDA (Note 2) / IEC / JIS standards conforming type LS-H92F LS-H91F LS-H91F-A
CE marking directive compliance EMC Directive, RoHS Directive
Applicable amplifiers LS-401(P), LS-401(P)-C2, LS-403


U-LG mode

0.2 to 30 m
0.656 to 98.425 ft
(Note 4)
0.1 to 7 m
0.328 to 22.966 ft
(Note 4)
0.1 to 5 m
0.328 to 16.404 ft
(Note 4)
STD mode 0.2 to 20 m
0.656 to 65.617 ft
(Note 4)
0.1 to 5 m
0.328 to 16.404 ft
(Note 4)
0.1 to 3 m
0.328 to 9.843 ft
(Note 4)
FAST mode 0.2 to 10 m
0.656 to 32.808 ft
(Note 4)
0.1 to 3 m
0.328 to 9.843 ft
(Note 4)
0.1 to 1 m
0.328 to 3.281 ft
(Note 4)
H-SP mode
Operation indicator Orange LED (lights up when the amplifier output is ON)
Laser emission indicator Green LED (lights up during laser emission)
Spot-shape adjuster
Ambient temperature -10 to +55 ℃ +14 to +131 ℉ (No dew condensation or icing allowed),
Storage: -20 to +70 ℃ -4 to +158 ℉
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance Incandescent light: 3,000 lx or less at the light-receiving face
Voltage withstandability 1,000 V AC for one min.
between all supply terminals connected together and enclosure
Insulation resistance 20 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure
Vibration resistance 10 to 500 Hz frequency, 1.5 mm 0.059 in (10 G max.) double amplitude in X, Y and Z directions for two hours each
Shock resistance 100 m/s2 acceleration (10 G approx.) in X, Y and Z directions three times each
Material Enclosure: PBT (Mounting part: PEI), Lens cover: Acrylic
Cable 0.1 mm2, single core two parallel shielded cables, 2 m 6.562 ft long (Connector for amplifier attached) (Note 5)
Weight Net weight: 30 g approx.
Gross weight: 40 g approx.
Net weight: 30 g approx.
Gross weight: 45 g approx.
Accessories RF-230(Reflector):
1 pc.
Warning label: 1 set
(Labels are written in
Japanese, English and
Chinese for compliance
with various standards.)
RF-330(Reflector):
1 pc.
Warning label: 1 set
(Labels are written in
Japanese, English and
Chinese for compliance
with various standards.)
RF-330(Reflector):
1 pc.
Explanation label: 1 set
(Labels are written in Japanese and Chinese for compliance with various standards.)
