Panasonic Photoelectric Sensor NX5-M10RA/-M10RB NX5-M30A NX5-M30B

Series#: Panasonic Photoelectric Sensor

Product Details

Qty:

Specification

Type Thru-beam
Type Long sensing range
Model No. NX5-M10RA NX5-M10RB NX5-M30A NX5-M30B
CE marking directive compliance Low Voltage Directive, EMC Directive, RoHS Directive
Sensing range 10 m
32.808 ft
30 m
98.425 ft
Sensing object φ20 mm φ0.787 in or more opaque object
(Note 4)
φ20 mm φ0.787 in or more opaque object
(Completely beam interrupted object)
(Note 4)
Hysteresis
Repeatability
(perpendicular to
sensing axis)
0.1 mm 0.004 in or less 0.2 mm 0.008 in or less
Supply voltage 24 to 240 V AC +10–15 % or 12 to 240 V DC +10–15 % Ripple P-P 10 % or less
Power consumption Emitter: 1 VA or less
Receiver: 2 VA or less
Emitter: 1.5 VA or less
Receiver: 2 VA or less
Output Relay contact 1 c
• Switching capacity:
250 V AC 1 A (resistive load)
30 V DC 2 A (resistive load)
• Electrical life:
500,000 or more switching operations (switching frequency 3,600 operations/hour)
100,000 or more switching operations (switching frequency 3,600 operations/hour)
• Mechanical life:
100 million or more switching operations (switching frequency 36,000 operations/hour)


Output operation

Light-ON Dark-ON Light-ON Dark-ON
Response time 10 ms or less
Operation indicator Red LED (lights up when the output is ON)
Stability indicator Green LED
(lights up under stable light received condition or stable dark condition)
Power indicator Red LED
(lights up when the power is ON)
Sensitivity adjuster Continuously variable adjuster
Automatic interference
prevention function
(Use optional interference
prevention filters)
Pollution degree 3 (Industrial environment)
Protection IP66 (IEC)
Ambient temperature –20 to +55 ℃ –4 to +131 ℉ (No dew condensation or icing allowed) (Note 6),
Storage: –30 to +70 ℃ –22 to +158 ℉
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance Incandescent light: 3,500 Lx or less at the light-receiving face
Voltage withstandability 1,500 V AC for one min. between power supply and output terminals,
1,000 V AC for one min. between relay contact terminals
Insulation resistance 20 MΩ, or more, with 500 V DC megger between power supply and output terminals, and between relay contact terminals
Vibration resistance 10 to 55 Hz frequency, 1.5 mm 0.059 in double amplitude in X, Y and Z directions two hours each
Shock resistance 500 m/s2 (50 G approx.) in X, Y and Z directions three times each
Emitting element Red LED (modulated) Infrared LED (modulated)


Peak emission
wavelength

660 nm 0.026 mil 880 nm 0.035 mil
Material Enclosure: Polycarbonate, Lens: Polycarbonate, Cover: Polycarbonate
Cable 0.3 mm2 5-core (thru-beam type emitter: 2-core) cabtyre cable, 2 m 6.562 ft long
Cable extension Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable (thru-beam type: both emitter and receiver).
Net weight Emitter: 100 g approx.
Receiver: 140 g approx.
Emitter: 125 g approx.
Receiver: 140 g approx.
Accessories Adjusting screwdriver: 1 pc.
