| Item | FP-XH M8N |
| Product number | AFPXHM8N16PD |
| No. of inputs/outputs | 8 DC inputs, 8 outputs (transistor) |
| High-speed counter | · 4 channels pulse input
· Counting range: -2,117,483,648 to 2,117,483,647 |
| Built-in interfaces | Ethernet port x 2, RS232C port x 1, USB port x 1 |
| Expansion | · Two application cassettes (16 I/Os each)
· Two communication cassettes (16 I/Os each) · FP-X expansion units (max. 7 units with 210 I/Os) · FP0R expansion units (max. 3 units with 96 I/Os) |
| Operation speed | Up to 7k steps:
· 0.04μs for basic instructions · 0.22μs for high-level instructions More than 7k steps: · 0.7μs for basic instructions · 1.73μs for high-level instructions |
| Program capacity | 24k / 32k / 40k steps (depending on system register setting) |
| Data register | 64k / 32k / 12k words (depending on system register setting) |
