| Item | Specifications |
| Ambient temperature | 0 to +55 °C +32 to +131 °F, At storage: -20 to +70 °C – 4 to +158 °F |
| Ambient humidity | 30 to 85 % RH (at +25 °C +77 °F, no dew condensation allowed),
At storage: 30 to 85 % RH (at +25 °C +77 °F, no dew condensation allowed) |
| Breakdown voltage
(Detection current: 5 mA) |
500 V AC for 1 minute
Input and output terminals ⇔ power and functional ground terminals (at control unit) Input terminals ⇔ Output terminals |
| Insulation resistance
(Test voltage: 500 V DC) |
100 MΩ or more
Input and output terminals ⇔ power and functional ground terminals (at control unit) Input terminals ⇔ Output terminals |
| Vibration resistance | 10 to 55 Hz, 1 sweep/min., double amplitude of
0.75 mm, 10 minutes each in X, Y, and Z directions |
| Shock resistance | 98 m/s2, 4 times each in X, Y, and Z directions |
| Noise immunity | 1,000 V (p-p) with pulse widths 50 ns and 1 μs
(using a noise simulator) |
| Operating condition | Free from corrosive gasses and excessive dust |
| Net weight | 100 g approx. |
| Control unit’s additional consumption current | 35 mA or less (at 24 V DC) [100 mA or less (internal 5 V DC)] |
