Panasonic Power DZ-S Relays

Series#: Panasonic Power Relays

Product Details

Qty:

Specification

Characteristics Specifications
1 Form A 5V DC ADZS12105 1 coil latching ADZS22105 2coil latching
1 Form A 12V DC ADZS12112 1 coil latching ADZS22112 2 coil latching
1 Form A 24V DC ADZS12124 1 coil latching ADZS22124 2 coil latching
Arrangement 1 Form A
Contact voltage drop (initial) Max. 0.09V (at 90A), Max. 0.05V (at 10A)
Contact material AgSnO2 alloy
Contact rating (resistive) 90 A 250 V AC
Max. switching power (resistive) 24,840 VA
Max. switching voltage 276 V AC
Max. switching current 90 A AC
Min. switching load (reference value)*1 100 mA 125 V AC
Insulation resistance (initial) Min. 1,000MΩ (at 500V DC) Measured portion is the same as the case of dielectric voltage.
Between open contacts 2,000 Vrms for 1 min. (detection current: 10 mA)
Dielectric strength (initial)

Between contact and coil

4,000 Vrms for 1 min. (detection current: 10 mA)
Surge withstand voltage (initial)*2

Between contact and coil

12,000 V
Operate time (initial) Max. 20 ms (at rated voltage, at 20°C, without bounce)
Release time (initial) Max. 20 ms (at rated voltage, at 20°C, without bounce)
Functional 300 m/s2 (half-wave pulse of sine wave: 11 ms; detection time: 10 μs)
Destructive 1,000 m/s2 (half-wave pulse of sine wave: 6 ms.)
Functional 10 to 55 Hz at double amplitude of 1.5 mm (detection time: 10 μs)
Destructive 10 to 55 Hz at double amplitude of 2.0 mm
Expected life Min. 105 (at 180 times/min.)
 Conditions for operation, transport and storage*3 *4 Ambient temperature: –40 to +85°C
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)
Unit weight Approx. 45 g
