| Item | Specifications | |
| Arrangement | 2 Form A 2 Form B, 3 Form A 1 Form B, 4 Form A | |
| Contact resistance (Initial) | Max. 50 mΩ (By voltage drop 6 V DC 1A) | |
| Nominal coil voltage | Single side stable | 2 coil latching |
| 3V DC | S4EB-3V | S4EB-L2-3V |
| 5V DC | S4EB-5V | S4EB-L2-5V |
| 6V DC | S4EB-6V | S4EB-L2-6V |
| 12V DC | S4EB-12V | S4EB-L2-12V |
| 24V DC | S4EB-24V | S4EB-L2-24V |
| 48V DC | S4EB-48V | S4EB-L2-48V |
| Electrostatic capacitance (initial) | Approx. 3pF | |
| Contact material | Au clad Ag alloy (Cd free) | |
| Thermal electromotive force (at nominal coil voltage) (initial) | Approx. 3µV | |
| Nominal switching capacity (resistive load) | 4 A 250 V AC, 3 A 30 V DC | |
| Max. switching power (resistive load) | 1,000 VA, 90 W | |
| Max. switching voltage | 250 V AC, 48 V DC (30 to 48 V DC at less than 0.5 A) | |
| Max. switching current | 4 A (AC), 3 A (DC) | |
| Min. switching capacity (Reference value)*1 | 100µA 100 m V DC | |
| Insulation resistance (Initial) | Min. 10,000MΩ (at 500V DC)
Measurement at same location as “Breakdown voltage” section. |
|
| Between open contacts | 750 Vrms for 1min. (Detection current: 10mA.) | |
| Between contact sets | 1,000 Vrms for 1min. (Detection current: 10mA.) | |
| Between contact and coil | 1,500 Vrms for 1min. (Detection current: 10mA.) | |
| Operate time [Set time] (at 20°C 68°F) | Max. 15 ms [15 ms] (Nominal coil voltage applied to the coil, excluding contact bounce
time.) |
|
| Release time [Reset time] (at 20°C 68°F) | Max. 10 ms [15 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.) (without diode) | |
| Functional | Min. 490 m/s2 (Half-wave pulse of sine wave: 11 ms; detection time: 10µs.) | |
| Destructive | Min. 980 m/s2 (Half-wave pulse of sine wave: 6 ms.) | |
| Functional | 10 to 55 Hz at double amplitude of 3 mm (Detection time: 10µs.) | |
| Destructive | 10 to 55 Hz at double amplitude of 4 mm | |
| Mechanical | Min. 108 (at 50 cps) | |
| Conditions for operation, transport and storage*2 | Ambient temperature: –55°C to +65°C –67°F to +149°F
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature) |
|
| Unit Weight | Approx. 8 g .28 oz | |
