| Type | Shielded type | |||
| Type | Bending-resistant cable | |||
| Model No. | GX-5S | GX-5SB | GX-5S-R | GX-5SB-R |
| CE marking directive compliance | EMC Directive, RoHS Directive | |||
| Max. operation distance (Note 2) | 1 mm 0.039 in ± 15% | |||
| Stable sensing range (Note 2) | 0 to 0.8 mm 0 to 0.031 in | |||
| Standard sensing object | Iron sheet 6 x 6 x t 1 mm 0.236 x 0.236 x t 0.039 in |
|||
| Hysteresis | 15 % or less of operation distance (with standard sensing object) |
|||
| Repeatability | 8 μm 0.315 mil or less | |||
| Supply voltage | 10 to 30 V DC Ripple P-P 10% or less | |||
| Current consumption | 15 mA or less | |||
| Output | NPN open-collector transistor – Maximum sink current: 200 mA (Note 3) – Applied voltage: 30 V DC or less (between output and 0 V) – Residual voltage: 1.5 V or less (at 200 mA sink current) 0.4 V or less (at 50 mA sink current) |
|||
|
Utilization category |
DC-12 or DC-13 | |||
| Output operation | Normally open |
Normally closed |
Normally open |
Normally closed |
| Max. response frequency | 1.5kHz | |||
| Operation indicator | Red LED (lights up when the output is ON) | |||
| Pollution degree | 3 (Industrial environment) | |||
| Protection | IP67 (IEC) | |||
| Ambient temperature | -25 to + 70 ℃ -13 to +158 ℉, Storage: -25 to +80 ℃ -13 to +176 ℉ |
|||
| Ambient humidity | 35 to 85 % RH, Storage: 35 to 95 % RH | |||
| Voltage withstandability | 500 V AC for one min. between all supply terminals connected together and enclosure | |||
| Insulation resistance | 50 MΩ, or more, with 500 V DC megger between all supply terminals connected together and enclosure | |||
| Vibration resistance | 10 to 55 Hz frequency, 1.5 mm 0.059 in double amplitude in X, Y and Z directions for two hours each | |||
| Shock resistance | 300 m/s2 acceleration (30 G approx.) in X, Y and Z directions ten times each | |||
| Material | Enclosure: Brass (Nickel plated) Resin part: ABS |
|||
| Cable | 0.14 mm2 3-core oil, heat and cold resistant cabtyre cable, 3 m 9.843 ft long | 0.15 mm2 3-core bending, oil and heat resistant cabtyre cable, 3 m 9.843 ft long | ||
| Cable extension | Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable. | |||
| Weight | Net weight: 55 g approx. | |||
| Accessories | MS-SS5 (Sensor mounting bracket): 1 pc. | |||
