| Type | NPN output | PNP output | ||
| Front sensing | GX-F6A(I) | GX-F6B(I) | GX-F6A(I)-P | GX-F6B(I)-P |
| Top sensing | GX-H6A(I) | GX-H6B(I) | GX-H6A(I)-P | GX-H6B(I)-P |
| CE marking directive compliance | EMC Directive, RoHS Directive | |||
| Max. operation distance (Note 3) |
1.6 mm 0.063 in ± 8 % | |||
| Stable sensing range (Note 3) |
0 to 1.3 mm 0 to 0.051 in | |||
| Standard sensing object | Iron sheet 12 x 12 x t 1 mm 0.472 x 0.472 x t 0.039 in | |||
| Hysteresis | 20 % or less of operation distance (with standard sensing object) |
|||
| Repeatability | Along sensing axis, perpendicular to sensing axis: 0.04 mm 0.002 in or less | |||
| Supply voltage | 12 to 24 V DC+10/-15% Ripple P-P 10 % or less | |||
| Current consumption | 15 mA or less | |||
| Output | NPN open-collector transistor – Maximum sink current: 100 mA – Applied voltage: 30 V DC or less (between output and 0 V) – Residual voltage: 2 V or less (at 100 mA sink current) |
PNP open-collector transistor – Maximum source current: 100 mA – Applied voltage: 30 V DC or less(between output and +V) – Residual voltage: 2 V or less (at 100 mA source current) |
||
|
Utilization |
DC-12 or DC-13 | |||
| Output operation | Normally open | Normally closed | Normally open | Normally closed |
| Max. response frequency | 400 Hz | |||
| Operation indicator | Orange LED (lights up when the output is ON) |
|||
| Pollution degree | 3 (Industrial environment) | |||
| Protection | IP68 (IEC), IP68G (Note 4, 5) | |||
| Ambient temperature | -25 to +70 ℃ -13 to +158 ℉, Storage: -40 to +85 ℃ -40 to +185 ℉ | |||
| Ambient humidity | 35 to 85 % RH, Storage: 35 to 95 % RH | |||
| Voltage withstandability | 1,000 V AC for one min. between all supply terminals connected together and enclosure | |||
| Insulation resistance | 50 MΩ, or more, with 500 V DC megger between all supply terminals connected together and enclosure | |||
| Vibration resistance | 10 to 500 Hz frequency, 3 mm 0.118 in double amplitude (Max. 20 G) in X, Y and Z directions for two hours each | |||
| Shock resistance | 10,000 m/s2 acceleration (1,000 G approx.) in X, Y and Z directions three times each | |||
|
Temperature |
Over ambient temperature range -25 to +70 ℃ -13 to +158℉: Within ±8 % of sensing range at +23℃ +73 ℉. | |||
| Voltage characteristics |
Within ±2 % for +10/-15 % fluctuation of the supply voltage | |||
| Material | Enclosure: PBT, Indicator part: Polyester | |||
| Cable | 0.15 mm2 3-core oil, heat and cold resistant cabtyre cable, 1 m 3.281 ft long | |||
| Cable extension | Extension up to total 100 m 328.084 ft is possible with 0.3 mm2, or more, cable. | |||
| Net weight | 15 g approx. | |||
