Panasonic Servo Motor MINAS A5 1KW MSME102GCHM/MSME102GCH
Panasonic Servo Motor MINAS A5 MSME 1.0 kW [Low inertia, Middle capacity]
Panasonic Servo Motor MINAS A5 1KW | AC400 V | ||||
Motor model *1 |
IP65 | MSME104GC□ | MSME104SC□ | ||
IP67 | MSME104G1□ | MSME104S1□ | |||
Applicable driver *2 |
Model No. | A5Ⅱ, A5 series | MDD◇T3420 | ||
A5ⅡE, A5E series | MDD◇T3420E | – | |||
Frame symbol | D-frame | ||||
Power supply capacity (kVA) | 1.8 | ||||
Rated output (W) | 1000 | ||||
Rated torque (N•m) | 3.18 | ||||
Momentary Max. peak torque (N•m) | 9.55 | ||||
Rated current (A(rms)) | 3.3 | ||||
Max. current (A(o-p)) | 14 | ||||
Regenerative brake frequency (times/min) Note)1 | Without option | No limit Note)2 | |||
DV0PM20048 | No limit Note)2 | ||||
Rated rotational speed (r/min) | 3000 | ||||
Max. rotational speed (r/min) | 5000 | ||||
Moment of inertia
of rotor (×10−4 kg•m2) |
Without brake | 2.03 | |||
With brake | 2.35 | ||||
Recommended moment of inertia ratio of the load and the rotor Note)3 | 15 times or less | ||||
Rotary encoder specifications Note)5 | 20-bit Incremental | 17-bit Absolute | |||
Resolution per single turn | 1048576 | 131072 |
