Panasonic Servo Motor MINAS A5 200W Break MSMJ022G1V/MSMD022G1V

Panasonic Servo Motor MINAS A5 200W Break MSMJ022G1V/MSMD022G1V
We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
100% Original and new,In stock by Panasonic Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Panasonic Servo Motor MINAS A5 200W Break	AC100 V
Motor model ＊1 IP65	MSMD021G1□	MSMD021S1□
A5Ⅱ, A5 series	MBD◇T2110
A5ⅡE, A5E series	MBD◇T2110E	–
Frame symbol	B-frame
Power supply capacity (kVA)	0.5
Rated output (W)	200
Rated torque (N•m)	0.64
Momentary Max. peak torque (N•m)	1.91
Rated current (A(rms))	2.5
Max. current (A(o-p))	10.6
Regenerative brake frequency (times/min) Note)1 Without option	No limit Note)2
DV0P4283	No limit Note)2
Rated rotational speed (r/min)	3000
Max. rotational speed (r/min)	5000
Moment of inertia of rotor (×10−4 kg•m2) Without brake	0.14
With brake	0.16
Recommended moment of inertia ratio of the load and the rotor Note)3	30 times or less
Rotary encoder specifications Note)5	20-bit Incremental	17-bit Absolute
Resolution per single turn	1048576	131072
