Panasonic Servo Motor MINAS A5 2KW | AC200 V | |
Motor model *1 IP65 | MDME202GC□ | MDME202SC□ |
IP67 | MDME202G1□ | MDME202S1□ |
A5Ⅱ, A5 series | MED◇T7364 | |
A5ⅡE, A5E series | MED◇T7364E | – |
Frame symbol | E-frame | |
Power supply capacity (kVA) | 3.3 | |
Rated output (W) | 2000 | |
Rated torque (N•m) | 9.55 | |
Momentary Max. peak torque (N•m) | 28.6 | |
Rated current (A(rms)) | 11.5 | |
Max. current (A(o-p)) | 49 | |
Rated rotational speed (r/min) | 2000 | |
Max. rotational speed (r/min) | 3000 | |
Moment of inertia
of rotor (×10−4 kg•m2) Without brake |
8.72 | |
With brake | 10.0 | |
Recommended moment of inertia ratio of the load and the rotor Note)3 | 10 times or less | |
Rotary encoder specifications Note)5 | 20-bit Incremental | 17-bit Absolute |
Resolution per single turn | 1048576 | 131072 |
