Panasonic Servo Motor MINAS A5 2KW | AC400 V | |
Panasonic Servo Motor MINAS A5
IP65 |
MDME204GC□ | MDME204SC□ |
Panasonic Servo Motor MINAS A5 IP67 | MDME204G1□ | MDME204S1□ |
A5Ⅱ, A5 series | MED◇T4430 | |
A5ⅡE, A5E series | MED◇T4430E | – |
Frame symbol | E-frame | |
Power supply capacity (kVA) | 3.3 | |
Rated output (W) | 2000 | |
Rated torque (N•m) | 9.55 | |
Momentary Max. peak torque (N•m) | 28.6 | |
Rated current (A(rms)) | 5.9 | |
Max. current (A(o-p)) | 25 | |
Regenerative brake frequency (times/min) Note)1
Without option |
No limit Note)2 | |
DV0PM20049 | No limit Note)2 | |
Rated rotational speed (r/min) | 2000 | |
Max. rotational speed (r/min) | 3000 | |
Moment of inertia
of rotor (×10−4 kg•m2) Without brake |
8.72 | |
With brake | 10.0 | |
Recommended moment of inertia ratio of the load and the rotor Note)3 | 10 times or less | |
Rotary encoder specifications Note)5 | 20-bit Incremental | 17-bit Absolute |
Resolution per single turn | 1048576 | 131072 |
