Panasonic Servo Motor MINAS A5 400W Break MSMJ042G1V/MSMD042G1V/G1D

Panasonic Servo Motor MINAS A5 400W Break MSMJ042G1V/MSMD042G1V/G1D
We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
100% Original and new,In stock by Panasonic Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Panasonic Servo Motor MINAS A5	AC100 V
Panasonic Servo Motor MINAS A5IP65	MSMD041G1□	MSMD041S1□
Panasonic Servo Motor MINAS A5IP67	–	–
Applicable driver ＊2Model No.A5Ⅱ, A5 series	MCD◇T3120
A5ⅡE, A5E series	MCD◇T3120E	–
Frame symbol	C-frame
Power supply capacity (kVA)	0.9
Rated output (W)	400
Rated torque (N•m)	1.3
Momentary Max. peak torque (N•m)	3.8
Rated current (A(rms))	4.6
Max. current (A(o-p))	19.5
Regenerative brake frequency (times/min) Note)1Without option	No limit Note)2
DV0P4282	No limit Note)2
Rated rotational speed (r/min)	3000
Max. rotational speed (r/min)	5000
Moment of inertiaof rotor (×10−4 kg•m2) Without brake	0.26
With brake	0.28
Recommended moment of inertia ratio of the load and the rotor Note)3	30 times or less
Rotary encoder specifications Note)5	20-bit Incremental	17-bit Absolute
Resolution per single turn	1048576	131072
