Panasonic Servo Motor MINAS A5 750W MHMD082G1U/G1C/MHMJ082G1U/G1C

Series#: Panasonic Servomotor

Product Details

  • Panasonic Servo Motor MINAS A5 750W MHMD082G1U/G1C/MHMJ082G1U/G1C
  • We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
  • We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
  • 100% Original and new,In stock by Panasonic Electric
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

Panasonic Servo Motor MINAS A5 750W MHMD AC200 V
Panasonic Servo Motor MINAS A5

IP65

MHMD082G1□ MHMD082S1□
Panasonic Servo Motor MINAS A5

IP67

A5Ⅱ, A5 series MCD◇T3520
 A5ⅡE, A5E series MCD◇T3520E
Frame symbol C-frame
Power supply capacity (kVA) 1.3
Rated output (W) 750
Rated torque (N•m) 2.4
Momentary Max. peak torque (N•m) 7.1
Rated current (A(rms)) 4.0
Max. current (A(o-p)) 17.0
Regenerative brake frequency (times/min) Note)1

Without option

No limit Note)2
DV0P4283 No limit Note)2
Rated rotational speed (r/min) 3000
Max. rotational speed (r/min) 4500
Moment of inertia

of rotor (×10−4 kg•m2)

Without brake

1.51
With brake 1.61
Recommended moment of inertia ratio of the load and the rotor Note)3 20 times or less
Rotary encoder specifications Note)5 20-bit Incremental 17-bit Absolute
Resolution per single turn 1048576 131072
