Panasonic Servo Motor MINAS A6 100W MHMF012L1V2M

Panasonic Servo Motor MINAS A6 100W MHMF012L1V2M
We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
100% Original and new,In stock by Panasonic Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Panasonic Servo Motor MINAS A6 100W	AC200 V
Panasonic Servo Motor MINAS A6 100W	MHMF012L1□□
Multifunction type	MADLT05SF
RS485 communication type *2	MADLN05SG
Basic type *2	MADLN05SE
Frame symbol	A-frame
Power supply capacity(kVA)	0.5
Rated output(W)	100
Rated torque(N•m)	0.32
Continuous stall torque(N•m)	0.33
Momentary Max. peak torque(N•m)	1.11
Rated current(A(rms))	1.1
Max. current(A(o-p))	5.5
Rated rotational speed (r/min)	3000
Max. rotational speed (r/min)	6500
Moment of inertia of rotor (×10−4 kg•m2) Without brake	0.071
With brake	0.074
Recommended moment of inertia ratio of the load and the rotor	30 times or less
Rotary encoder specifications *3	23-bit Absolute
Resolution per single turn	8388608
