Panasonic Servo Motor MINAS A6 2900W MGMF292L1H6M
Panasonic Servo Motor MINAS A6 | AC200 V |
Panasonic Servo Motor MINAS A6 MGMF | MGMF292L1□□ |
Multifunction type | MFDLTB3SF |
RS485 communication type *2 | MFDLNB3SG |
Basic type *2 | MFDLNB3SE |
Frame symbol | F-frame |
Power supply capacity(kVA) | 5.0 |
Rated output(W) | 2900 |
Rated torque(N•m) | 18.5 |
Continuous stall torque(N•m) | 18.5 |
Momentary Max. peak torque(N•m) | 45.2 |
Rated current(A(rms)) | 19.3 |
Max. current(A(o-p)) | 67 |
Regenerative brake frequency (times/min) Note)Without option | No limit Note)2 |
DV0P4285×2 | No limit Note)2 |
Rated rotational speed(r/min) | 1500 |
Max. rotational speed(r/min) | 3000 |
Moment of inertia of rotor (×10−4 kg•m2)Without brake | 46.9 |
With brake | 52.3 |
