Panasonic Servo Motor MINAS A6 2kW | AC200 V |
Panasonic Servo Motor MINAS A6 IP67 | MHMF202L1□□ |
Multifunction type | MEDLT83SF |
RS485 communication type *2 | MEDLN83SG |
Basic type *2 | MEDLN83SE |
Frame symbol | E-frame |
Power supply capacity(kVA) | 3.8 |
Rated output(W) | 2000 |
Rated torque(N•m) | 9.55 |
Continuous stall torque(N•m) | 11.5 |
Momentary Max. peak torque(N•m) | 28.6 |
Rated current(A(rms)) | 12.5 |
Max. current(A(o-p)) | 53 |
Regenerative brake frequency (times/min) Note)Without option | No limit Note)2 |
DV0P4285 | No limit Note)2 |
Rated rotational speed(r/min) | 2000 |
Max. rotational speed(r/min) | 3000 |
Moment of inertiaof rotor (×10−4 kg•m2)
Without brake |
55.7 |
With brake | 61.0 |
Recommended moment of inertia ratio of the load and the rotor | 5 times or less |
Rotary encoder specifications *3 | 23-bit Absolute |
Resolution per single turn | 8388608 |
