Panasonic Servo Motor MINAS A6 3KW MDMF302L1G6M

Panasonic Servo Motor MINAS A6 3KW MDMF302L1G6M
We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
100% Original and new,In stock by Panasonic Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Panasonic Servo Motor MINAS A6 3KW MSMF	AC200 V
Panasonic Servo Motor MINAS A6 IP67	MSMF302L1□□
Multifunction type	MFDLTA3SF
RS485 communication type *2	MFDLNA3SG
Basic type *2	MFDLNA3SE
Frame symbol	F-frame
Power supply capacity(kVA)	5.2
Rated output(W)	3000
Rated torque(N•m)	9.55
Continuous stall torque(N•m)	11.0
Momentary Max. peak torque(N•m)	28.6
Rated current(A(rms))	18.1
Max. current(A(o-p))	77
Regenerative brake frequency (times/min) Note)1Without option	No limit Note)2
DV0P4285×2	No limit Note)2
Rated rotational speed (r/min)	3000
Max. rotational speed (r/min)	5000
Moment of inertia of rotor (×10−4 kg•m2) Without brake	7.04
With brake	7.38
Recommended moment of inertia ratio of the load and the rotor	15 times or less
Rotary encoder specifications *3	23-bit Absolute
Resolution per single turn	8388608
