Panasonic Servo Motor MINAS A6 50w MSMF5AZL1V2M

Panasonic Servo Motor MINAS A6 50w MSMF5AZL1V2M
We are First Class Panasonic servomotors dealer and Panasonic servomotors distributor in China.
We can Supply Panasonic electric automation parts,such as Panasonic PLC,Panasonic Servo Motor&Panasonic servo drive,Panasonic VFD,Panasonic Relay and Panasonic Sensor.
100% Original and new,In stock by Panasonic Electric
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Panasonic Servo Motor MINAS A6	AC100 V
Panasonic Servo Motor MINAS A6	MSMF5AZL1□□
Mufti-function type	MADLT01SF
RS485 communication type *2	MADLN01SG
Basic type *2	MADLN01SE
Frame symbol	A-frame
Rated rotational speed(r/min)	3000
Max. rotational speed(r/min)	6000
Panasonic Servo Motor MINAS A6	AC200 V
Motor model *1	MSMF5AZL1□□
Multifunction type	MADLT05SF
RS485 communication type *2	MADLN05SG
Basic type *2	MADLN05SE
Frame symbol	A-frame
Power supply capacity(kVA)	0.5
Rated output(W)	50
Rated torque(N•m)	0.16
Continuous stall torque(N•m)	0.16
Momentary Max. peak torque(N•m)	0.48
Rated current(A(rms))	1.1
Max. current(A(o-p))	4.7
Rotary encoder specifications *3	23-bit Absolute
Resolution per single turn	8388608
