| Item | Specifications | ||||
| Arrangement | 1 Form C | 2 Form C | |||
| Initial contact resistance, max. | Max. 50 mW (By voltage drop 6 V DC 1A) | ||||
| Nominal coil voltage 3V | DS1E-S-DC1.5V | DS1E-SL2-DC1.5V | |||
| Nominal coil voltage 5V DC | DS1E-S-DC3V | DS1E-SL2-DC3V | |||
| Nominal coil voltage6V DC | DS1E-S-DC5V | DS1E-SL2-DC5V | |||
| Nominal coil voltage 9V DC | DS1E-S-DC6V | DS1E-SL2-DC6V | |||
| Nominal coil voltage 12V DC | DS1E-S-DC9V | DS1E-SL2-DC9V | |||
| Nominal coil voltage 24V DC | DS1E-S-DC12V | DS1E-SL2-DC12V | |||
| Nominal coil voltage 48V DC | DS1E-S-DC24V | DS1E-SL2-DC24V | |||
| Contact material | Ag+Au clad | ||||
| Nominal switching capacity | 2 A 30 V DC (resistive load) | ||||
| Max. switching power | 60 W, 125 VA (resistive load) | ||||
| Max. switching voltage | 220 V DC, 250 V AC | ||||
| Max. carrying current | 3 A | ||||
| Min. switching capacity (Reference value)*1 | 10mA 10m V DC | ||||
| Nominal operating power | Single side stable (M | type: 400 mW, | S type: 200 mW); | ||
| Insulation resistance (Initial) | Min. 100MW (at 500V DC)
Measurement at same location as “Initial breakdown voltage” section. |
||||
| Between open contacts | 1,000 Vrms for 1min.
(500 Vrms for 1min: 1 Form C high sensitivity type) (Detection current: 10mA.) |
||||
| Between contact and coil | 1,500 Vrms for 1min.
(1,000 Vrms for 1min: 1 Form C high sensitivity type) (Detection current: 10mA.) |
||||
| Temperature rise | Max. 65°C
(By resistive method, nominal coil voltage applied to the coil, contact carrying current: 2A.) |
||||
| Operate time [Set time] (at 20°C 68°F) | Max. 10 ms [10 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.) | ||||
| Release time [Reset time] (at 20°C 68°F) | Max. 5 ms [10 ms] (Nominal coil voltage applied to the coil, excluding contact bounce time.) (without diode) | ||||
| Functional | 10 to 55 Hz at double amplitude of 3.3 mm (Detection time: 10ms.) | ||||
| Destructive | 10 to 55 Hz at double amplitude of 5 mm | ||||
| Mechanical | Min. 108 (107: 1 Form C latching type) (at 600 cpm) | ||||
| Electrical | Min. 5´105 rated load (at 60 cpm) | ||||
| Conditions for operation, transport and storage*3 | Ambient temperature: –40°C to +70°C –40°F to +158°F Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature) | ||||
| Max. operating speed (at rated load) | 60 cpm | ||||
| Unit weight | Approx. 3 g .11 oz | Approx. 4g .14oz | |||
