Model | LT-3300L/LT-3300S/LT-3300T | LT-3301L |
Application*1 | FLASH EPROM 6MB | |
Data Backup | SRAM 128K byte
Used lithium battery for backup memory |
|
Serial Interface | COM1: RS232C/RS422/RS485
Asynchronous Transmission: Data Length: 7 bit/8 bit Parity: none, Odd or Even Stop Bit: 1bit/2bit Data transmission Speed: 2400bps to 115.2Kbps Connector: DSUB-9pin plug |
|
Ethernet Interface | Ethernet
(IEEE802.3u,10BASE-T/100BASE-TX) Connector: modular jack connector (RJ- 45) |
– |
DIO Interface | The interface to external I/O equipment Input/Output points: 16-point inputs, 16-point outputs
Connector: 38 pins |
|
AUX Interface/ Expansion Unit | Interface for external additional unit only (such as communication equipment) (external) | |
USB Host Interface | Conforms to USB1.1. (TYPE-A conn.) x 1 Power Supply Voltage: DC5V ±5% Output Current: 500mA (max.) Communication Distance: 5m (max.) | |
EX Module Interface | Interface for Pro-face’s EX Modules (Up to three EX modules can be connected) | |
Clock Accuracy*2 | ± 65 seconds/ month (at room temperature) | |
Control Memory
Variable Area |
64 KB SRAM (uses lithium battery) | |
Program Area |
132 KB FLASH EPROM |
