Specifications
|
Proface Touch Screen HMI | Proface Touch Screen HMI | Proface Touch Screen HMI | Proface Touch Screen HMI |
Model | GP-4114T | GP-4115T | GP-4115T3 | GP-4116T |
Order Numbers | PFXGP4114T2D | PFXGP4115T2D | PFXGP4115T3D | PFXGP4116T2D |
Graphics Display Resolution | 480 x 272 pixels | |||
Display
Type |
4.3” TFT Color LCD | |||
Colors | 65k colors | |||
Backlight | White LED Backlit, service life: 50,000 hrs. at 25°C (77°F) and 24 hr. operation | |||
Brightness Control | 16 Levels, adjustable through system menu and software | |||
Touch Panel | Resistive Film (Analog) 1024 x 1024 pixels | |||
Memory
Application |
8MB | |||
Backup Memory | FLASH EPROM 128MB | 320KB NVRAM | FLASH EPROM 128MB | |
Interfaces
Serial (COM1) |
— | Asynchronous Transmission:RS-232C Data Length: 7 or 8 bits Stop Bit:
1 or 2 bits Parity: None, odd, or even Data Transmission Speed: 2,400 (1,200). 115,200 bps Connector: 2-piece terminal block 9 pin x 1 |
Asynchronous Transmission:RS-232C Data Length: 7 or 8 bits Stop Bit:
1 or 2 bits Parity: None, odd, or even Data Transmission Speed: 2,400 (1,200). 115,200 bps Connector: 2-piece terminal block 9 pin x 1 |
Asynchronous Transmission: RS-422/485Data Length: 7 or 8 bits
Stop Bit: 1 or 2 bits Parity: None, odd, or even Data Transmission Speed: 2,400 (1,200). 115,200 bps, 187,500 bps (MPI) Connector: 2-piece terminal block 9 pin x 1 |
Ethernet | 1x Ethernet IEEE802.3i/u, 10-BASE-T /100-Base-T, RJ45 | — | — | — |
USB | 1x USB 2.0 (Host) Type A with DC5V Power Supply 1x USB 2.0 (Host) Type mini-B |
