5.7" Proface Touch screen HMI PFXGP4301TADW

Series#: Proface HMI

Product Details

Qty:

Specification

Specifications Proface Touch screen HMI PFXGP4301TADW
Model PFXGP4301TADW
Graphics Display Resolution 320 x 240 pixels (QVGA)
Display Type and Size TFT Color LCD (5.7 inch)
Display Colors 65,536 Colors (no blink), 16,384 (blink)
Display Area W115.2 x H86.4 mm [W4.54 x H3.40 in.]
Touch Screen Resistive film analog 1024 x 1024 resolution
USB USB Type-A (2.0) x 1 , USB mini-B (2.0) x1
Serial COM1: RS-232C Asynchronous Transmission Data Length: 7 or 8 bits, Parity: None, Odd or Even, Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, Connector: D-Sub9 (plug)

COM 2: RS-422/485 Asynchronous Transmission Data Length: 7 or 8 bits, Parity: None, Even or Odd Stop Bit: 1 or 2 bits, Data Transmission Speed: 2,400 bps to 115.2 kbps, 187.5kbps (MPI) Connector: D-Sub9 (plug)

Ethernet IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX Connector: Modular jack (RJ-45) x 1
Backlight White LED (User nonreplaceable parts. When replacement is required, contact your local distributor.
Brightness and Contrast Controls 8 levels of adjustment available via touch panel
Programming Memory 8MB FEPROM (GP-Pro EX V3.0 or later)
Backup Memory 128kb SRAM with battery backup
