Schneider miniature circuit-breaker(MCB) Resi9 2P C6~C40 6A~40A

Series#: Schneider Circuit Breaker

Product Details

  • Schneider miniature circuit-breaker(MCB) Resi9 2P C6~C40 6A~40A
  • We are First Class schneider circuit breaker distributors and schneider circuit breaker supplier,schneider electric resellers in China.
  • We have Large inventory for all schneider circuit breaker:schneider air circuit breaker,schneider type b circuit breaker,schneider electric circuit breaker,schneider fp circuit breaker,schneider fvr circuit breaker,schneider generator circuit breaker.schneider high voltage circuit breaker,schneider circuit breaker mcb,schneider circuit breaker mccb and schneider circuit breaker accessories.
  • 100% Original and new,In stock by Schneider Electric.
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

range Resi9
product name Resi9 MCB
product or component type Miniature circuit-breaker
device application Distribution
poles description 2P
number of protected poles 2
[In] rated current 20 A at 30 °C
network type AC
trip unit technology Thermal-magnetic
curve code C
breaking capacity 3000 A Icn at 230 V AC 50/60 Hz conforming to EN/IEC 60898-1
standards EN/IEC 60898-1
product certifications CEBEC



network frequency 50/60 Hz
[Ue] rated operational voltage 230 V AC 50/60 Hz
magnetic tripping limit 5…10 x In
limitation class 3 conforming to EN/IEC 60898-1
[Ui] rated insulation voltage 440 V AC 50/60 Hz
[Uimp] rated impulse withstand voltage 4 kV
control type Toggle
local signalling ON/OFF indication
mounting mode Clip-on
mounting support DIN rail
comb busbar and distribution block compatibility Bottom: biconnect
9 mm pitches 4
height 85 mm
width 36 mm
depth 75 mm
embedding depth 44 mm
net weight 0.211 kg
colour White
mechanical durability 20000 cycles
electrical durability 10000 cycles AC 50/60 Hz conforming to EN/IEC 60898-1
locking options description Padlock in OFF position
connections – terminals Tunnel type terminals (bottom) – <= 16 mm² – flexible
Tunnel type terminals (bottom) – <= 25 mm² – rigid
Tunnel type terminals (top) – <= 25 mm² – rigid
Tunnel type terminals (top) – <= 16 mm² – flexible

tightening torque 2 N.m
