Schneider Miniature Relays RXM4LB2F7 AC120V

Series#: Schneider Miniature Relays

Product Details

Schneider Miniature Relays RXM4LB2F7 AC120V
miniature plug-in relay – Zelio RXM2L – 4 C/O – 120 V AC – 3 A – with LED
We are First Class Schneider Relays dealer and Schneider Relays distributor in China.
We can Supply All kinds Schneider Relays,such as Schneider Interface Relays,Schneider Miniature Relays,Schneider Power Relays,Schneider Timer Relays,Schneider Control Relays and Schneider Relays Socket.
100% Original and new,In stock by Schneider Electric.
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

range of product	Zelio Relay
series name	Miniature
product or component type	Plug-in relay
device short name	RXM
coil interference suppression	Without
utilisation coefficient	20 %
sale per indivisible quantity	10

contact operation	Standard
[Uc] control circuit voltage	120 V AC 50/60 Hz
[Ithe] conventional enclosed thermal current	3 A at -40…55 °C
status LED	With
control type	Without push-button
[Ui] rated insulation voltage	250 V conforming to IEC
[Uimp] rated impulse withstand voltage	3.6 kV during 1.2/50 µs conforming to IEC 61810-7
contacts material	Silver alloy (Ag/Ni)
[Ie] rated operational current	3 A (AC-1/DC-1) NO conforming to IEC 1.5 A (AC-1/DC-1) NC conforming to IEC
minimum switching current	10 mA
maximum switching voltage	250 V AC 250 V DC
minimum switching voltage	17 V
load current	3 A at 250 V AC 3 A at 28 V DC
maximum switching capacity	750 VA AC 84 W DC
minimum switching capacity	170 mW
operating rate	<= 1200 cycles/hour under load <= 18000 cycles/hour no-load
mechanical durability	10000000 cycles
electrical durability	100000 cycles for resistive load
average coil consumption in VA	1.2 AC
drop-out voltage threshold	>= 0.15 Uc AC
operating time	20 ms between coil de-energisation and making of the Off-delay contact 20 ms between coil energisation and making of the On-delay contact
average resistance	4500 Ohm network: AC at 20 °C +/- 15 %
rated operational voltage limits	96…132 V AC
protection category	RT I
test levels	Level A group mounting
operating position	Any position
CAD overall width	21 mm
CAD overall height	27 mm
CAD overall depth	46 mm
net weight	0.033 kg
dielectric strength	2000 V AC between coil and contact 2000 V AC between poles 1000 V AC between contacts
safety reliability data	B10d = 100000
